Formax CT-20 Assembly, Operation And Parts Manual

Conveyor stacker
Hide thumbs

Advertisement

Quick Links

Download this manual
CT-20
Conveyor Stacker
8/2021
Assembly, Operation & Parts Manual
First Edition

Advertisement

loading
Need help?

Need help?

Do you have a question about the CT-20 and is the answer not in the manual?

Questions and answers

Related Manuals for Formax CT-20

Summary of Contents for Formax CT-20

  • Page 1 CT-20 Conveyor Stacker Assembly, Operation & Parts Manual First Edition 8/2021...

  • Page 2: Specifications

    TABLE OF CONTENTS SPECIFICATIONS UNPACKING CONTENTS ASSEMBLY SETUP AND OPERATION PARTS SPECIFICATIONS POWER 110 VAC 60 HZ FUSE 1 AMP / 110V BELT SPEED VARIABLE, 0 TO 100 FT PER MINUTE DIMENSIONS WITH TRAY 45.5” L x 12.5” W x 25” - 34” H (from top of deck to the floor) Capacity Up to 450 #10 Envelopes* WEIGHT...
  • Page 3 COMPONENTS 1. Infeed plate 2. Stacker wheel assembly 3. Sequence stacking tray 4. Infeed guides 5. Thumbscrews 6. Infeed roller brackets 7. Conveyor 8. Stand Non-Operator side Front Rear Operator side...
  • Page 4 ASSEMBLY Mount the conveyor to the stand. Turn the conveyor up on the non-operator side and remove the four center screws from the bottom plate of the conveyor. Place the conveyor ontop of the stand and align the holes. Use the removed button head screws to mount the conveyor to the stand.
  • Page 5 Mount the infeed guides to the operator and non-operator side of the conveyor with the thumscrews provided. The guides should be mounted so that the flared edge is facing out and towrd the front of the conveyor. Mount the Sequesnce Stacking Tray. Remove the five button head screws from the rear of the conveyor and use them to mount the tray to the rear of the conveyor.

  • Page 6: Setup And Operation

    SETUP AND OPERATION Runout Button Speed Control Power Connect the cord to the conveyor and plug it into the wall outlet. Set the height of the conveyor to match the outfeed of the printer/feeder. Carefully loosen the two knobs on either side of the conveyor stand to raise or lower the stand height, a second person may be required.
  • Page 7 PARTS...
  • Page 9 CONVEYOR PARTS ITEM PART # DESCRIPTION 375-5699 SCREW 10-32 X 1/4 BUTTON HD CA 360-2316 BOTTOM PAN, 36” N/P 360-3079 INFEED PLATE, CT20 320-0011 WEIGHTED STACKER WHEEL, OFP 361-8136 STACKER WHEEL ARM 380-5538 ** OPX ** NYLON PELLET 376-0077 10-32 Set Screw 332-0187 ROD, INFEED-OUTFEED WHEELS 372-0124...
  • Page 10 STAND PARTS...
  • Page 11 STAND PARTS ITEM PART # DESCRIPTION 360-3053 STAND, OUTER SLEEVE 360-3054 STAND, INNER PANEL 360-3055 STAND, BOTTOM 381-0175 PUSH IN RETAINER, TEXTURED 381-0174 PUSH IN RETAINER 372-0059 CASTOR 323-0041 END CAP 1 in x 1/4 DIA. 372-0127 HAND KNOB, 1/2 - 13 STUD 377-2611 WASHER 1/4 SPLIT 375-2802...
