- Page 1 FD 4170 Cut Sheet Burster OPERATOR MANUAL FIRST EDITION 4/2010...
-
Page 3: Table Of Contents
TABLE OF CONTENTS TOPIC PAGE SPECIFICATIONS UNPACKING & SET-UP INPUT SIDE OUTPUT SIDE OUTPUT CONVEYOR (OPTIONAL) CONTROL PANEL POWERING UP ADJUSTING PROCESSING SPEED LCD DISPLAYS FOR SET-UP & OPERATION STEPS OF SET-UP & OPERATION MANUAL SETTING EXAMPLES OF CUT SIZES LOADING PAPER PREPARATION BEFORE OPERATION COUNTER DISPLAY &... -
Page 5: Specifications
SPECIFICATIONS Speed: 5-level speed adjustment: 42, 64, 89, 114, 140 sheets/minute Feed Tray Capacity: Up to 400 sheets Paper Size: 5” - 17” H x 4” - 11” W Paper must not have staples, clips, adhesive or holes. Paper Weight: 13# bond - 110# index (58 - 175 gsm) Min./Max. -
Page 6: Input Side
■ Part Names and Their Functions INPUT SIDE ● Appearance (front side) Name Function Number Description Function Paper Feed Tray Paper feed tray Paper to be burst is set here. Support Tray Open this tray prior to operating to support paper. Support tray Paper to be burst is set here. -
Page 7: Output Side
● Appearance (exit side) OUPUT SIDE Number Description Function Stacker Burst forms stack here upon exiting. Name Function Paper Guide ● Option Should be set according to the width of the burst forms. Receives ejected paper. Stacker Paper Stopper Should be set according to the length of the burst forms. Set according to the width of ejected paper. -
Page 8: Control Panel
1. Connect the ‘female plug’ of the power cord to CONTROL PANEL ● Operation Panel the ‘inlet’. 2. Connect the ‘male plug’ of the power cord to the ‘outlet’. Number Description Function ■ Usable Paper “-” Button Use to decrease cut size on LCD display Name Function “+”... -
Page 9: Lcd Displays For Set-Up & Operation
■ Display for Operation and Setting ■ Display for Operation and Setting ■ ■ ■ Display for Operation and Setting Display for Operation and Setting ■ Display for Operation and Setting Display for Operation and Setting ● Display for start LCD DISPLAYS FOR SET-UP AND OPERATION ●... -
Page 10: Steps Of Set-Up & Operation
STEPS OF SETUP AND OPERATION ■ Procedure of Use Unpacking & Set-up (page 1) ■ Preparation Before Using Machine (p.17) ■ Turning On the Power (p.18) (page 4) (pg 7) (p.19) Manual Setting: Standard mode inputting cut size on a case-by-case basis (pg 11) (p.24) Preset Selection Setting: Convenient function registering frequently used cut size in advance and easily retrieving the registered cut size... -
Page 11: Manual Setting
Manual setting is standard mode that each cut size is input on a case-by-case basis. MANUAL SETTING [ NOTES ] When cut size is registered as Preset Setting, “Preset Selection Setting” is automatically selected. Manual Setting is a standard mode in which each cut size is input individually for each project. “Manual Setting”... -
Page 12: Loading Paper
■ Setting Paper LOADING PAPER ■ Setting Paper 1. Fan the air into sheets by riffling. 1. Fan the air into sheets by riffling. 1. Fan the sheets to loosen, which will decrease static electricity and reduce the chance of a paper jam or [ IMPORTANT ] misfeed. -
Page 13: Preparation Before Operation
PREPARATION BEFORE OPERATION ■ ■ Preparation Before Operation ■ Preparation Before Operation Preparation Before Operation ■ Preparation Before Operation 1．Set bursting speed. 1．Set bursting speed. 1．Set bursting speed. 1. Set bursting speed Setting range: Speed 1 - 5 5. Counter appears on the LCD while the machine Setting range: Speed 1 - 5 1．Set bursting speed. -
Page 14: Counter Display & Reset
4. Start the machine by pressing the START key. * The machine automatically stops after processing. COUNTER DISPLAY AND RESET Counter Display 1. To display the number of cut sheets after a previous reset, press and hold the STOP/C button in stand-by mode. 2. -
Page 15: Preset Tables
“17-2” 11” x 8.5” “17-3” 11” x 5.67” 11” x 17” Vertical “17-4” 11” x 4.25” ■ Preset Table PRESET TABLES 10 “17-5” 11” x 3.4” 11 “17-6” 11” x 2.83” 12 “PASS” ----- ----- Fixed preset list Display Paper size Number Finished size Cut size... -
Page 16: To Input Fixed Preset
TO INPUT FIXED PRESET ■ ■ Fixed Preset Registration/Cancel Fixed Preset Registration/Cancel Example: No. 0 8.5” x 11” Vertical 2-cut Fixed Preset Registration Fixed Preset Registration Select preset No. 0 by pressing the speed up or speed down button. Example: No.0 8.5” x 11” Vertical 2-cut Example: No.0 8.5”... -
Page 17: To Input Free Size Preset
■ Fixed Preset Registration/Cancel TO INPUT FREE SIZE PRESET ■ Fixed Preset Registration Free Size Preset Registration/Cancel Example: No.0 8.5” x 11” Vertical 2-cut Example: No. 13 5.5” ■ Free Size Preset Registration Free Size Preset Registration/Cancel 1. Select preset No.0 by pressing the speed up key and the slow down key. * The display blinks before registration. -
Page 18: Optional Conveyor Operation
Please contact our service person concerning the optional conveyer unit. This is operation mode that an optional conveyer unit independently operates when the optional The optional Output Conveyor can be installed in the paper outfeed of the FD 4170. conveyer unit is installed on the machine. -
Page 19: Error Display Guide
■ Error Display ERROR DISPLAY GUIDE * 2 error displays appear in turn. Display Status and Solutions [ FEEd ]→[ Err. ] Status: Paper jam in the paper feed part Solutions: Check the paper feed tray and remove jammed paper. After removing the jammed paper, press the STOP/C key to clear the error display. -
Page 20: Clearing Error Messages
How to deal with “[ FEEd. ]→[ Err. ]” ■ Clearing Error and How to Deal with Trouble CLEARING ERROR MESSAGES ● Paper feed part 1. Remove the jammed paper at the entrance of ● Paper feed part How to deal with “[ FEEd. ]→[ Err. ]” the machine. - Page 21 How to deal with [ SEt ]→[ PAPE. ] How to deal with [ SEt ]→[ PAPE. ] 1. Move the paper feed tray up/down lever 1. Move the paper feed tray up/down lever downwards to place the paper on the paper downwards to place the paper on the paper feed tray.
- Page 22 How to deal with [ PAPE. ]→[ LEFt ] How to deal with [ Cut ]→[ Err. ] How to deal with[ PASS ]→[ Err. ] 1. Press the “O” side of the power switch to turn off the power and remove the power plug from the outlet.
- Page 23 How to deal with [ Err.1 ] How to deal with [ Err.1 ] How to deal with [ Err.1 ] * If an excessive load is applied to the machine during operation due to paper jam and so on, * If an excessive load is applied to the machine the breaker works for safety and the machine during operation due to paper jam and so on,...
- Page 24 ● Removing paper using the JOG key ● Removing paper using the JOG key 1. Close the safety cover. 1. Close the safety cover. 2. Remove the paper from the paper feed tray. 2. Remove the paper from the paper feed tray. 3.
- Page 25 ● Cleaning sensor part 1. Press the “O” side of the power switch to turn off the power and remove the power plug from the outlet. WARNING Be sure to remove the power plug from the outlet when working near movable parts due to paper jam and so on.
