8.5.5 Tag Setup Menu
Master Station Tag
FCU address
FCU's Tag
This is the page for editing tag names which may be assigned to the master station and the field units.
Commands available:
1
-
2
-
3
-
-
-
-
MENU
Issue 1.0
1>M/S Tag
2>FCU
3>Tag
Edit master station's tag
Change field unit address
Edit field unit tag
Go on to next FCU
Go back to previous FCU
Return to previous menu
Pakscan IIS Technical Manual
MSTAG001
2
FCUTAG02
Editing a tag: An arrow appears beneath the
character being edited
MSTAG001
^
Commands available:
- The Up and Down arrow keys are used
to scroll through the characters which can
be used in tag names. These are:
'A' to 'Z', '0' to '9', plus '-', and a
'Space'. (Numbers 0 to 9 can however,
be entered directly via the keypad)
- abandon editing and start again
CLEAR
- accept current character and move onto
LOAD
the next one
- finish editing
MENU
