Installation Instructions

Before Installation

Please read these instructions carefully and keep for future
reference.
The information in this document is subject to change without
notice. For updates please refer to our website.
CAUTION
!
・Do not use the products outside the rated power supply voltage
range specified in the Specifications. It may cause a fire or
damage to equipment.
・Do not disassemble, repair, or modify the products. It may cause
a fire or electric shock.
・Make sure to turn the power off before commencing any wiring
work. Otherwise it may cause electric shock or damage to
equipment.
・Do not use any tester other than the one specified for testing. It
may cause damage to equipment.
Note
・Follow the requirements for the installation of the products in
accordance with the Specifications. Otherwise it may cause
malfunction.
・The products should not be installed in the following places, as it
may cause damage to equipment:
-
Place with plenty of air flow (close to a ventilation fan, air
conditioner, or place with drafts)
-
Place close to heating appliance
-
Place with a constantly high temperature or humidity
-
Place with lots of dust or insects
-
Place with exhaust gas such as garage
-
Place where oil, dust, iron powder, chemicals, or hydrogen
sulphide may occur or affect the products
These instructions explain how to install and test UL Listed Nittan
detectors and bases.
For the details of each product, please refer to "Instruction Manual"
on the website: http://www.nittan.com
1-54-5 SASAZUKA, SHIBUYA-KU, TOKYO 151-8535, JAPAN
Table 1: UL Listed Product Instruction Manual
Product category
Model number
Control Panel
NFU-7000 series
EVA-PY
EVA-PYH
EVA-H2
Detector
EVA-H2-H
EVA-DPH
EVCA-P(-Z)
EVA-UB4
EVA-UB4-6
EVA-STB-RL
Base
EVA-STB-SCI
EVA-S6 Base
EVA-DIP-SCI
EVA-DOP-SCI
EVA-DOP
-AC240V-SCI
Module
EVA-SCI
EVA-SCM-SCI
EVA-MiniIP
EVA-ZMU-SCI
End of line
PCE
Adapter Mounting
STBA-ADP
Plate
!
Install the detectors/bases in accordance with these instructions,
applicable NFPA standards, local codes, and the authorities
having jurisdiction. Failure to follow these instructions may result
in failure of detectors to initiate an alarm condition. Nittan is not
responsible for detectors and bases that have been improperly
installed, tested, or maintained.
Table 2: Electrical box for base
BASE Model
3-1/2" Oct
EVA-UB4
EVA-UB4-6
EVA-S6 Base
EVA-STB-RL
EVA-STB-RL
with
STBA-ADP
EVA-STB-SCI
EVA-STB-SCI
with
STBA-ADP
Connect wiring to the detectors/bases as shown in the Section2.
Detectors and bases may be mixed on the same initiating loop as
long as the number of two-wire powered detectors does not
exceed the specifications of the control panel. For the
specifications of detectors/bases, see Table 3.
NITTAN COMPANY, LIMITED
http://www.nittan.com
Manual part
number
LT-894NIT
DW1401832
DW1401831
DW1401833
DW1401834
DW1500110
DW1401959
DW1401853
DW1401852
DW1401960
DW1401989
DW1401991
DW1401992
DW1401994
DW1401995
DW1401993
DW1401990
DW1401961
DW1402124
CAUTION
Applicable electrical box
4" Oct
4" Square
-
-
-
-
-
-
-
-
DW1500274
Mar 6, 2017
Version
Rev 2.1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K2
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K1
Rev.K3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NFU-7000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nittan NFU-7000 Series

  • Page 1 Failure to follow these instructions may result Place with exhaust gas such as garage in failure of detectors to initiate an alarm condition. Nittan is not Place where oil, dust, iron powder, chemicals, or hydrogen responsible for detectors and bases that have been improperly installed, tested, or maintained.
  • Page 2 Conformity UL268 and UL464 Refer to the Installation and Operation Manual of control panel NFU-7000 series to determine correct loop load and maximum loop resistance for devices connected to each loop. EVCA-P(-Z) can be connected with the analog addressable module EVA-ZMU-SCI only.
  • Page 3 AUX. PWR- Connect PCE for open circuit monitoring. To UL Listed control Connect to UL Listed two wire EVA-S6 Base Connect to UL Listed analog detector panel NFU-7000 series detector EVCA-P(-Z) for Class A EVA-PY, EVA-PYH, EVA-H2 wiring. EVA-DPH. LOOP+...
  • Page 4 3. Installation 3.3 Use of dust cover SLC line impedance is 50Ω at maximum and the maximum length If the dust cover is not used during construction work, the is 2km. exposure to a slightly dusty environment can cause false alarms Please refer to “Terminal”...
  • Page 5 Direct Heat Method 10. Reset the heat detector at the control panel. Detectors (Heat Calibur HO-HC11 Heat Detector Tester) that fail these tests should be cleaned in accordance with MAINTENANCE Section in the instruction manual Turn Master Power switch on and press the Power of the detector and retested.
  • Page 6 Scientific Corp.). Please follow the manufacturer’s recommendations on FOR WARRANTY SERVICE, RETURN TO: their use. OVERSEAS BUSINESS DIVISION NITTAN COMPANY, LIMITED For EVA-PY and EVA-PYH: 1-54-5 SASAZUKA, SHIBUYA-KU, TOKYO Where the sensitivity limits for the Analyzer are 0.6 %/ft. 151-8535, JAPAN - 1.3 %/ft.
