Nittan EVA-PY3 Instruction Manual

Analog photoelectric smoke detector
Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual
EVA-PY3
Analog Photoelectric Smoke Detector
Before Installation
Please read these instructions carefully and keep for future reference.
The information in this document is subject to change without notice. For updates please refer to our website.
Do not use the products outside the rated power supply voltage range specified in
the Specifications. It may cause a fire or damage to equipment.
Do not disassemble, repair, or modify the products. It may cause a fire or electric
shock.
Make sure to turn the power off before commencing any wiring work. Otherwise it
may cause electric shock or damage to equipment.
Note: Follow the requirements for the installation of the products in accordance with the Specifications. Otherwise it
may cause malfunction.
Note: Do not install the product in any location where oil, dust, iron powder, chemicals, or hydrogen sulphide may occur
or affect the product. It may cause damage to equipment.
Section 1 – INTRODUCTION
1.1
General description
The EVA-PY3 is an attractively-styled, low profile, analog addressable, photoelectric smoke detector for use with the
Nittan Control panel NFU-7000 series in analog fire alarm systems.
This analog addressable photoelectric smoke detector has a specific detector address to provide exact detector
locations throughout the installation. This allows for constant monitoring of the detector sensitivity and reports the
detectors condition to the fire alarm control panel.
1.2
LED Indicator
LED Indicators for 360° visibility (OMNIVIEW
Green LED flashes in normal operation.
Red LED illuminates and Green LED flashes in an alarm condition.
1.3
EVA-PY3 features
* Low profile, stylish appearance
* Soft addressing
* Low monitoring current
* Supplied with protective dust cover
* OMNIVIEW
TM
360
o
LED Indicator for polling and fire alarm indication
* Photoelectric detector, detecting visible particles of combustion
* Automatic compensation for smoke detector contamination
1-54-5 SASAZUKA, SHIBUYA-KU, TOKYO 151-8535, JAPAN
! CAUTION
! CAUTION
! CAUTION
360°) of EVA-PY3 operate as follows:
TM
1
NITTAN COMPANY, LIMITED
https://www.nittan.com/english
DW2000742 Rev.K1
May. 11, 2022
