NISM ST-P-OM INSTRUCTION MANUAL PAGE: 1 of 8 ST-P-OM ISSUE No: 2 Photoelectric Smoke Detector DATE: 03/10/11 ST-P-OM CONVENTIONAL PHOTOELECTRIC SMOKE DETECTOR INSTRUCTION MANUAL NISM-ST-P-OM-INST MANUAL-001 ISS 2 03/10/11 www.acornfiresecurity.com... - Page 2 Photoelectric Smoke Detector DATE: 03/10/11 INTRODUCTION The ST-P-OM Photoelectric Smoke Detector is an updated version of the ST- P sensortec photoelectric smoke detector The ST-P-OM is an elegantly designed, low profile detector which is aesthetically pleasing, thus enabling it to blend unobtrusively into modern working environments.
- Page 3 ST-P-OM ISSUE No: 2 Photoelectric Smoke Detector DATE: 03/10/11 Section 1 - INTRODUCTION ST-P-OM The ST-P-OM is an attractively-styled, low profile photoelectric smoke detector for use in conventional CONTENTS:- fire detection systems. Section 1 - Introduction - Page 3 The ST-P-OM has a chemically etched, stainless...
- Page 4 Section 3 - DETECTOR MODELS Section 5 - INSTALLATION The ST-P-OM photoelectric smoke detector is In normal use, the ST-P-OM detector will be installed supplied, as standard, with four terminals. at ceiling level. Pass the field wiring through the cable hole in the centre and from the rear of the base.
- Page 5 Maintenance: smoke condition. The ST-P-OM detector is a high quality product engineered for reliability. In order to obtain optimum i) Take any necessary precautions at the control performance, periodic maintenance is required. If...
- Page 6 Ambient Temperature Range: C to +55 Standard: EN54-7: 2000 EMC Conformance: BS EN50130-4:1996 (Immunity) BS EN61000-6-3:2001 (Emissions) Mass: 118g (excluding base) IP Rating: IP40 Section 8 - ENVIRONMENTAL NISM-ST-P-OM-INST MANUAL-001 ISS 2 03/10/11 www.acornfiresecurity.com...
- Page 7 ST-P-OM INSTRUCTION MANUAL PAGE: 7 of 8 ST-P-OM ISSUE No: 2 Photoelectric Smoke Detector DATE: 03/10/11 Section 10 CONNECTIONS UB-4 Base UB-4SD Base UB-4R Base STB-4SE Base Section 11 DIMENSIONS 15mm 33mm Æ 104mm NISM-ST-P-OM-INST MANUAL-001 ISS 2 03/10/11 www.acornfiresecurity.com...
- Page 8 Section 11 DISPOSAL This symbol on the ST-P-OM indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
