The new ST-P-AS photoelectric smoke sensor forms part of a brand new
range of analogue addressable fire detectors from Nittan (UK) Ltd called
SENSORTEC-ANALOGUE.
The ST-P-AS is a low cost, elegantly designed, low profile sensor which
is aesthetically pleasing, thus enabling it to blend unobtrusively into
modern working environments.
The ST-P-AS features the very latest technological advancements,
increasing reliability and performance.
The ST-P-AS is compatible with our existing 'AS' protocol and is
compatible with leading panel manufacturers.
SENSORTEC-ANALOGUE.......
NITTAN (UK) LTD - BRINGING STYLE INTO FIRE DETECTION SYSTEMS
ST-P-AS
ANALOGUE-ADDRESSABLE
PHOTOELECTRIC SMOKE SENSOR
INSTRUCTION MANUAL
