GPS 95 STD
TM
PERSONAL NAVIGATOR
OWNER'S MANUAL
KOJC
KPTS
KSGF
SM

Advertisement

Table of Contents
loading

Related Manuals for Garmin GPS 95 STD Personal Navigator

Summary of Contents for Garmin GPS 95 STD Personal Navigator

  • Page 1 GPS 95 STD PERSONAL NAVIGATOR OWNER'S MANUAL KOJC KPTS KSGF...
  • Page 2 GPS 95 STD Personal Navigator OWNER'S MANUAL...
  • Page 3 GARMIN. Information in this document is subject to change without notice. GARMIN reserves the right to change or improve their products and to make changes in the content without obligation to notify any person or organization of such changes or improvements.
  • Page 4 Afterwards, try a trip of your own to realize the value of the GPS 95 as your Personal Navigator our Product Support Department is eager to serve you. GARMIN is fully committed to your satisfaction as a customer. PREFACE .
  • Page 5 CAUTION The GPS system is operated by the government of the United States which is solely responsible for its accuracy and maintenance. The system is under development and is subject to changes which could affect the accuracy and performance of all GPS equipment. Although the GPS 95 is a precision electronic NAVigation AID (NAVAID), any NAVAID can be misused or misinterpreted, and therefore become unsafe.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS CHAPTER INTRODUCING THE GARMIN GPS 95 1.1 Capabilities 1.2 Basic Package 1.3 Optional Accessories 1.4 Operational Modes GETTING STARTED 2.1 Front Panel 2.2 Softkey Operation 2.3 Cursor and Fields 2.4 Keypad Operation 2.5 Entering Data 2.6 Viewing Messages 2.7 Turning the GPS 95 On...
  • Page 7 6.6 Active Route 6.7 Route List AUTOSTORE 7.1 Creating Waypoints with Autostore 7.2 Building Routes with Autostore GPS STATUS AND AUXILIARY FUNCTIONS 8.1 Bar Graph Display 8.2 Satellite Status Page 8.3 Satellite Skyview Page 8.4 Auxiliary Menu 8.5 Operating Mode/Filters 8.6 Track Log Setup...
  • Page 8 MESSAGES GLOSSARY AND NAVIGATION TERMS B.1 Definitions B.2 Course To Steer (CTS) INSTALLATION AND MAINTENANCE C.1 Specifications C.2 Electrical Wiring C.3 Yoke Mount Installation C.4 Yoke Mount Operation C.5 Portable Antenna Installation C.6 Battery Pack Operation C.7 Maintenance C.8 Product Support MAP DATUMS UTC TIME TO LOCAL TIME OFFSET INDEX...

  • Page 9: Introducing The Garmin Gps 95

    Vertical navigation guides you to your cruising altitude and puts you in the traffic pattern before landing. · Alarms: An alarm clock and timer allow the GPS 95 to watch the clock for you. Arrival and CDI alerts help you safely navigate your aircraft.

  • Page 10: Basic Package

    The detachable antenna is placed directly on the right side of the unit. The carrying case will protect your GPS 95 when the unit is not is use.

  • Page 11: Optional Accessories

    When using the GPS 95 inside the cockpit it may be desirable to use the remote antenna cable for better satellite visibility. The detachable antenna is removed from the GPS 95 and replaced by one end of the remote antenna cable.

  • Page 12: Operational Modes

    GPS 95 to your PC-compatible computer. You may also edit this data and upload it back into the GPS 95. With the software kit you can plot data files and/or display current position in real-time on a grid map. Data files can be printed for future reference.

  • Page 13: Getting Started

    Information displayed on the LCD is commonly referred to as a “page.” The GPS 95 works with softkey operation. At the bottom of the screen is a list of page options. To select a different page, press the appropriate softkey below the desired option.

  • Page 14: Cursor And Fields

    CURSOR AND FIELDS Cyclic Field Confirmation Field The area of the page which is highlighted in reverse video is called the cursor. The cursor may be moved to locations on the page called fields which allow you to enter data or change options. You will encounter five types of fields.
  • Page 15 Pressing GOTO allows you to instantly define a destination waypoint and plot a course from present position to that destination. (See Chapter 4.) Pressing AUTOSTOre allows you to capture your present AUTO position instantaneously. (See Chapter 7.) Pressing NAV allows you to view position and navigation information as well as the Map Display.

  • Page 16: Entering Data

    · Press CLR if you enter an incorrect letter. · Press ENT when all the characters are entered. The GPS 95 features a keypad feedback tone which will sound each time you press a key. If you enter data which is not appropriate for the field, the feedback tone will quickly sound three times indicating an error.

  • Page 17: Viewing Messages

    GPS 95 outside to a location that is well away from buildings and other structures that might limit its view of the sky. After you turn your GPS 95 on, it will conduct a series of self tests and display the following notice:...
  • Page 18 15 seconds.) If the GPS 95 has been moved a considerable distance since it was last used, additional time may be required as the unit performs an AutoLocate will automatically locate satellites and compute your position regardless of your location or where the unit was last used.

  • Page 19: Turning The Gps 95 Off

    2.8 TURNING THE GPS 95 OFF 2.9 LEARNING TO USE THE GPS 95 If you are using the GPS 95 for the first time, you are encouraged to read Chapter 3 which introduces the GPS 95's waypoint features, Chapter 4 on the use of the GOTO key, and Chapter 5 for navigating to a waypoint.

  • Page 20: Waypoints

    CHAPTER 3 WAYPOINTS The GPS 95 allows you to store up to 500 user waypoints. A basic waypoint consists of an identifier (up to six letters and/or numbers) and its location. You will have the opportunity to use waypoints extensively while operating the GPS 95.

  • Page 21: Waypoint Definition Page

    3.1 WAYPOINT DEFINITION PAGE The Waypoint Definition Page allows you to create, edit and review waypoint information. This page displays the following waypoint information: 1) Waypoint identifier 2) Location (latitude/longitude or grid system) 3) Reference waypoint identifier 4) Bearing from reference waypoint to selected waypoint 5) Distance from reference waypoint to selected waypoint 6) User comments Waypoints are selected by the identifier that you assign.

  • Page 22: Creating Waypoints

    When a waypoint identifier has been entered that does not exist in memory the GPS 95 will assume you wish to create a new waypoint. You may create a new waypoint using one of two methods: direct position entry (latitude/ longitude or grid system) or relative to an existing waypoint.
  • Page 23 To create a waypoint offset from a reference waypoint... · With the Waypoint Definition Page displayed, press the right arrow key until the cursor is over the waypoint identifier field. · Enter the identifier of the new waypoint using the alphanumeric and arrow keys.

  • Page 24: Waypoint List

    3.3 WAYPOINT LIST The Waypoint List Page allows you to view all stored waypoints in your GPS 95. The list may be scrolled, with the arrow keys, to view all the waypoints. From this page, waypoints may be selected for deletion, renaming or to activate a GOTO.

  • Page 25: Using Waypoints

    CLR to cancel. 3.4 USING WAYPOINTS You may use waypoints on many GPS 95 pages. A waypoint is selected by entering its identifier and pressing ENT. The GPS 95 also offers a waypoint scanning feature which will simplify waypoint entry.

  • Page 26: Reviewing Waypoints

    You may limit the scan to the level that you desire. For example, if you enter “C” the GPS 95 will scan through all waypoints that begin with the letter “C”, but, if you enter “CRY” the GPS 95 will display only those waypoints that begin with “CRY”.

  • Page 27: Proximity Alarm Waypoints

    “Proximity Overlap”. As long as the overlap remains this message will be displayed each time the GPS 95 is turned on. (WARNING: If you enter the overlap area the unit will only inform you of the nearest waypoint.)

  • Page 28: Nearest Waypoints

    3.7 NEAREST WAYPOINTS An important feature on the GPS 95 is the ability to display up to nine nearest waypoints within 200 nautical miles of your present position. The bearing and distance to each nearest waypoint is also displayed. The nearest waypoint feature can be critical in finding a safe landing location in the event of an in- flight emergency.

  • Page 29: Getting There Fast - Goto

    To activate the GOTO function... · Press GOTO. The GOTO Page will be displayed with the cursor on the GOTO waypoint field. If the GPS 95 is currently navigating to a waypoint, that waypoint will be offered as the default GOTO waypoint.
  • Page 30 · Press GOTO. The GOTO Page will be displayed. · Press CLR. The GOTO waypoint name will become blank. · Press ENT. The GPS 95 will start to navigate using the active route, if it has been programmed. (See Chapter 6.) Otherwise, the GPS 95...

  • Page 31: Navigation Information

    NAVIGATION INFORMATION The GPS 95 features four navigation pages. You may select the desired page by pressing NAV and, if needed, the appropriate softkey. Navigation Summary Page Map Display 5.1 NAVIGATION SUMMARY PAGE GOTO or Active Leg Field #1 Field #3...
  • Page 32 The top line of the Navigation Summary Page will indicate this condition, as illustrated below. If the GPS 95 has acquired satellites, but is not navigating to a waypoint (i.e., no GOTO destination or route has been activated), the top line of the Navigation Summary Page will indicate that no destination has been defined, as illustrated below.

  • Page 33: Map Display

    Notice that the Navigation Summary Page has four cyclic fields. With these cyclic fields you may configure your GPS 95 to display navigation information according to your preferences. (See Appendix B for a description of navigation terms.) The field options are as follows: Field #1 (top left) ·...
  • Page 34 The GPS 95 also features a Map Display which shows a graphic top view of your location. The current ground speed is indicated at the top right corner of the display. The top left corner defines the orientation of the Map Display: “North up”, “Ground track up”, or “Desired track up.”...

  • Page 35: Map Configuration

    5.3 MAP CONFIGURATION The Map Configuration Page allows you to tailor the GPS 95’s Map Display to your preferences. As previously stated, the Map Display can show waypoints, the active route, your track history and/or waypoint identifiers.

  • Page 36: Present Position

    As mentioned earlier, the Present Position Page is automatically displayed when the GPS 95 is turned on and a position is obtained. The top line of this page displays your ground track (TRK) and ground speed (GS). The next two lines indicate your current position according to the coordinate format and map datum selected.

  • Page 37: Sample Trip

    GPS 95. If your position has moved a considerable distance since the unit was last used, the GPS will perform an AutoLocate (See Section 2.7.) This process can take up to ten minutes as the GPS 95 determines its new location. Alternatively, you may enter a more accurate initial position directly on the Present Position Page to speed up the acquisition process.
  • Page 38 Place the cursor on the operational mode field using the right arrow key. Press CLR until “Simulator?” is selected. Press ENT to accept simulator mode. The cursor is now on the reference waypoint identifier. GARMIN, will be entered here using the alphanumeric keys. The waypoint,...
  • Page 39 GARMIN [N 38° 57.003' W 94° 44.767'].) The cursor is over the reference bearing. Since the simulation will begin at GARMIN you do not need to define a reference bearing from this point. Press ENT. The cursor is over the reference distance.
  • Page 40 From your starting location at the “GARMIN” waypoint you may plot a course and navigate to a nearby airport. For this sample trip you will fly to KCOU, Columbia Regional Airport (N38° 49.078' W92° 13.175'). Before you can navigate to this waypoint it must be added to the GPS 95's memory.
  • Page 41 Enter the latitude of KCOU (N38° 49.078'). Begin by selecting the proper hemisphere. If “N” for north is not *If need to select proper displayed, press CLR. hemisphere Press ENT when the proper hemisphere is selected. Enter the latitude degrees. Press the “3”...
  • Page 42 5-12 Navigating to a waypoint is easy. Press GOTO and the GPS 95 will display the GOTO Page, as illustrated. Notice that the cursor is to the right of “GOTO”. On this field you will enter the identifier of your destination waypoint, KCOU.
  • Page 43 The GPS 95's simulator mode allows you to enter a ground speed which is used to animate the navigation displays. To enter a simulated speed... *Continue pressing the alphanumeric keys as needed to enter ground speed the Navigation Summary Page. You may recall from Section 5.1 that this information is viewed by highlighting one of the four cyclic fields and pressing CLR.
  • Page 44 CLR until desired scale is selected The simulated trip has demonstrated only a small portion of the GPS 95's many features. Take a moment to experiment with your new unit. Review Chapter 5 covering types of information on the Navigation Summary Page and the Map Display.

  • Page 45: Routes

    (Active to waypoint) Active Leg KTUL The GPS 95 offers a route navigation feature for you to navigate along a pre- defined sequence of waypoints. The GPS 95 route capability allows you to create and store twenty routes, numbered 0 through 19, containing up to 30 waypoints each. Routes 1 to 19, the storage routes, can be activated to travel either in the order you entered the waypoints or in reverse order.

  • Page 46: Route Definition

    There are 3 route pages. You may select the desired page by pressing RTE and, if needed, the appropriate softkey. Route Definition Page 6.1 ROUTE DEFINITION The Route Definition page allows you to create, change, review, copy, and activate routes. Remember that route 0 is always the active route. If you create a route in route 0, you should copy it into an empty storage route (1- 19).

  • Page 47: Creating And Copying Routes

    On the route number field, you may choose between routes 0 through 19 with CLR. Next to this is a route action field which allows you to activate the route, clear the route, copy the route to another location, or invert the order of the waypoints in a route and activate it.

  • Page 48: Activating And Inverting Routes

    6.3 ACTIVATING AND INVERTING ROUTES Routes are also activated on the Route Definition Page. You may activate any route in the displayed order, or in reverse order. (NOTE: Remember, when a new route is activated, the previous contents of route 0 will be overwritten.

  • Page 49: Deleting Routes

    · If you attempt to add a waypoint to a route that already contains 30 waypoints, you will be informed with the message, “Route is Full”. NOTE: You may also edit a route from the Active Route Page. (See Section 6.6.) 6.5 DELETING ROUTES You may delete an unwanted route from the Route Definition Page.

  • Page 50: Route List

    The waypoint list displays route waypoints starting with the “active to” waypoint. For each waypoint, additional information is available. The first column displays Distance (DIS). The second column is a cyclic field that displays Estimated Time Enroute (ETE, in hours/minutes or minutes/seconds, as appropriate), Estimated Time of Arrival (ETA), or Desired Track (DTK).

  • Page 51: Autostore

    The Autostore function allows you to capture your position at the touch of a button for future reference. This function saves your current position as a waypoint. Additionally, you may record your navigation path by inserting the captured waypoints directly into a route. The Autostore Page displays the waypoint identifier, captured position and optional storage route.

  • Page 52: Building Routes With Autostore

    7.2 BUILDING ROUTES WITH AUTOSTORE The GPS 95’s Autostore are flying. During your flight; as you reach each airport, NAVAID, landmark, or turn to a new heading; you may capture your position and add it to a route.
  • Page 53 To build a route with Autostore · From the starting location, press AUTOSTO to capture the position. (NOTE: The unit must me in 2D or 3D navigation mode when capturing your starting position. If the unit is still acquiring satellites, and you press AUTOSTO, the last known position will be captured and saved.) ·...

  • Page 54: Gps Status And Auxiliary Functions

    CHAPTER 8 GPS STATUS AND AUXILIARY FUNCTIONS The GPS 95 contains a vast array of functions, many of which you may custom tailor to your preferences. Additionally, the unit can provide current status information regarding the satellites being received and display messages relevant to your current operations.

  • Page 55: Bar Graph Display

    The GPS 95 is in the process of searching the sky for visible satellites. You will also be informed of this condition with a “Searching the Sky” message.

  • Page 56: Satellite Status Page

    8.2 SATELLITE STATUS PAGE be used as absolute measures of accuracy. (See Appendix B for definitions of these terms.) The GPS 95 is unusable (possibly due to incorrect initialization data or abnormal satellite conditions). Turn the unit off and back on.

  • Page 57: Satellite Skyview Page

    “north up” and is useful in determining whether a satellite signal is being blocked by part of the aircraft, buildings, The GPS 95's auxiliary pages allow you to do setup functions to customize your unit and E6-B calculations to plan your flight.

  • Page 58: Track Log Setup

    The Operating Mode/Filters Page also allows you to set position and velocity filters. Changing the filter settings will alter the GPS 95's response time to changes in track or ground speed. To change the filter settings, highlight the appropriate field and cycle through the filter settings (automatic, fast, medium or slow) with CLR.
  • Page 59 The track storing function may be turned on and off by highlighting the first status field and pressing CLR. From the next field, the track may be set to “wrap” around through available memory (deleting the oldest track information and using the memory to store the new track position), or to “fill” available memory and then stop.

  • Page 60: Units/Heading Setup

    · Enter the resolution range, and press ENT. When your position moves this defined range off a projected course line, a new position is added to the stored ground track. 8.7 UNITS/HEADING SETUP minutes (hddd°mm.mmm’); degrees, minutes and decimal seconds (hddd°mm’ss.s”);...

  • Page 61: Alarms/Cdi Setup

    · The on/off cyclic field is highlighted. If the alarm is not turned on, press CLR. The GPS 95 also features an alarm clock which can provide an alarm tone and the message “Alarm Clock” at a time that you specify.
  • Page 62 When you are off course, you then steer towards the “D-Bar”. A “Steer to D-Bar” orientation is the typical setting for aviation use and will make the GPS 95's graphic CDI respond much like the CDI on your instrument panel.

  • Page 63: Date/Time

    8.9 DATE/TIME The cyclic field for “Display” options determines which time, UTC or Local, will be displayed on all other GPS 95 pages. To display UTC or local time... · Highlight the time display field. · Press CLR to select the desired time reference.

  • Page 64: Audio And Display Setup

    · Highlight the tone option field. · Press CLR to select the desired option. You may also adjust the contrast of the GPS 95 display to your preferences. To change the display contrast... · Highlight “Change Contrast?” and press ENT.

  • Page 65: Interface Setup

    (NONE/NMEA), RTCM input/NMEA output (RTCM/NMEA) or RTCM input (RTCM/NONE). A second cyclic field also appears when the GARMIN input/output is selected. The GARMIN option allows you to exchange data such as waypoints, routes, track logs and satellite almanac data with another GPS 95 or with a PC-compatible computer.
  • Page 66 (NOTE: With RTCM/NMEA selected the RTCM baud rate is automatically set to 1200 or 4800.) If the RTCM input is selected, but the GPS 95 is not connected to an RTCM device, the unit will alert you with the message “No RTCM Input”. If the GPS 95 does not receive sufficient data to compute a DGPS-corrected position, the message “No DGPS Position”...

  • Page 67: Map Datum Selection

    NOTE: The GPS 95 is shipped from the factory with the WGS 84 datum selected. To change the pre-defined datum...

  • Page 68: Messages

    · Enter your current altimeter setting and press ENT. · Enter the total air temperature (TAT). The GPS 95 will display the resulting density altitude and true airspeed. (NOTE: TAT is the temperature of the air including the heating effect caused by speed.

  • Page 69: Sunrise/Sunset Planning

    · Place the cursor over the heading (Hdg) field. · Enter the current heading (magnetic) from your heading indicator and press ENT. The GPS 95 will display the wind direction, speed, and the head/tail wind you are encountering. 8.15 SUNRISE/SUNSET PLANNING To calculate the sunrise/sunset times for a waypoint...

  • Page 70: Trip And Fuel Planning

    (a given leg or all of the route) to calculate for. The final step is to enter speed and fuel flow rates. The GPS 95 will then calculate the desired track (DTK), fuel requirements (REQ), distance (DIS), and estimated time enroute (ETE).

  • Page 71: Vertical Navigation Planning

    · Highlight the “Flow:” field and enter the estimated fuel flow followed by ENT. · The GPS 95 will now display the calculated figures. NOTE: When “all” is selected, no desired track (DTK) will be shown since this value only applies to an individual leg.
  • Page 72 · You now have defined how far before, or after, the indicated waypoint you wish to be at the final altitude. The GPS 95 will display the required vertical speed. To activate the VNAV function...
  • Page 73 GPS 95 will display an “Invalid profile” status on the bottom line. The GPS 95 will display “No Active Waypoint” on the bottom line if no route, or GOTO destination, has been activated.

  • Page 74: Sample Trip Using Routes

    If you have changed these parameters the unit may display slightly different data than presented here. You are planning a trip from St. Petersburg, Florida to the Dry Tortugas and then on to Key West, Florida . Turn on the GPS 95 to begin this sample trip. Dry Tortugas (DRYTG) CHAPTER 9 St.
  • Page 75 GPS 95 to acquire satellites. You will set the operating mode to “simulator” and define the starting location (St. Petersburg). Setting the simulator mode and initial position... The welcome screen is displayed and the GPS 95 performs several self tests.
  • Page 76 showing the current operational mode. Press the right arrow to place the cursor on the operational mode field. Press CLR (repeatedly) until “Simulator?” is displayed. *Press repeatedly until Press ENT to select simulator mode. “Simulator” is displayed The cursor is on the reference identifier field.
  • Page 77 *If needed to select proper hemisphere *Continue pressing the alphanumeric keys to enter the latitude minutes displayed indicating that the position coordinates for St. Petersburg, Florida (KPIE) are not known. Enter the latitude for KPIE (N27° 54.646'). Begin by selecting the proper hemisphere.
  • Page 78 41.244') in the same manner as was *Enter the longitude using used for the latitude. Press ENT once the same steps shown data is entered into each field. above Press the right arrow key twice to place the cursor on “USE?” and press ENT.
  • Page 79 Before you begin the trip, all waypoints used along the route must be in memory. The location for St. Petersburg was just created when the initial position was set. The position coordinates for the Dry Tortugas (DRYTG) and Key West (KEYW) must still be entered. Below are the identifiers and locations for waypoints used in this sample trip: Indent KPIE...
  • Page 80 Enter the latitude of DRYTG (N24°38.430'). Begin by selecting the proper hemisphere, If “N” for north is *If needed to select not displayed, press CLR. proper hemisphere Press ENT when the proper hemisphere is selected. Enter the latitude degrees. Press the “2”...
  • Page 81 GOTO function as described in Chapter 4. (Select GOTO DRYTG, then, upon reaching DRYTG, select GOTO KEYW.) However, for this sample trip, the route capabilities of the GPS 95 will be utilized. Enter the longitude of DRYTG (W083°08.301') in the same manner as was used for the latitude.
  • Page 82 To create the sample route... *Plus RTE softkey, if needed Press RTE and the RTE softkey, if needed, to select the Route Definition Page. Press the right arrow to place the cursor on the route number field. Press CLR to select route 1. Notice that the route is empty;...
  • Page 83 As you see, you have just created a route that will take you from St. Petersburg, over the Dry Tortugas and on to Key West. Once activated, the GPS 95 will calculate navigation data based on the route. 9-10 Continue pressing the alphanumeric and, if needed, arrow keys until the waypoint identifier is added to the route.
  • Page 84 To activate the sample route... *Continue pressing until “Activate” is highlighted In order to animate the GPS 95's displays you will need to enter a simulated speed. To set the simulated speed... *Plus NAV softkey, if needed Press the right arrow key until “Activate?”...
  • Page 85 *Continue pressing the alphanumeric key to enter the ground speed As your flight progresses, you can monitor the nearest waypoints at any time. This feature can be particularly valuable in the event of an in-flight emergency. To view the nearest waypoints... *Plus NRST softkey, if needed 9-12...
  • Page 86 Chapter 8 for information concerning custom settings. Doing so will help you understand what each setting will do. · If you wish to stop the simulation, simply turn the GPS 95 off. We recommend that you delete the route and waypoint created in this simulation prior to using your unit again.

  • Page 87: A Messages

    Expect a rapid change in the CDI. Memory Battery Low - The battery that sustains user memory is low and should be replaced by an authorized GARMIN service center as soon as possible. Failure to do so may result in loss of stored data, including all...
  • Page 88 Osc Needs Adjustment - The GPS 95 has detected excessive drift in its internal crystal oscillator which may result in longer acquisition time. The unit should be taken to an authorized GARMIN service center as soon as possible. Poor GPS Coverage - The GPS 95 cannot acquire sufficient satellites necessary to provide navigation.
  • Page 89 The GPS 95 will not allow more than 30 waypoints per route. Route Not Empty - An attempt has been made to copy a route to a non- empty route. The GPS 95 will not allow you to copy a route to a non-empty route.

  • Page 90: B Glossary And Navigation Terms

    APPENDIX B GLOSSARY AND NAVIGATION TERMS B.1 DEFINITIONS This section provides an illustration of and definitions for the terms used in this manual.
  • Page 91 Velocity/time terms: Ground speed. GS is the speed measured relative to a ground position; also known as velocity over ground (VOG). Estimated time of arrival. ETA is the estimated time you will reach the “active to” waypoint based on current GS. This time is selectable as either UTC or local.

  • Page 92: B.2 Course To Steer (Cts)

    B.2 COURSE TO STEER (CTS) Course To Steer is a GARMIN exclusive that recommends an optimal direction to steer that will guide you to the course and proceed efficiently...
  • Page 93 As an example, suppose you activate the route illustrated above. The GPS 95 chooses the closest leg with a desired track of 45 degrees but your position happens to be two nautical miles off course. The unit will automatically compute the optimal course to steer (which is due north in this example).

  • Page 94: C.1 Specifications

    Humidity: PERFORMANCE Receiver: Frequency: Acquisition Time: (typical) APPENDIX C GPS 95 SPECIFICATIONS Waterproof Portable: 3.23"w x 6.26"h x 1.46"d (82mm x 159mm x 37mm) Fixed: 3.23"w x 4.87"h x 1.46"d (82mm x 124mm x 37mm) 14 ounces (0.4 kg) without battery pack 19 ounces (0.54 kg) with battery pack...
  • Page 95 Update Rate: Accuracy: Dynamics: INTERFACES NMEA 0180 NMEA 0182 NMEA 0183 (Version 1.5; December 1987) Approved sentences: GPBWC, GPGLL, GPRMB, GPRMC, GPR00, GPWPL, GPXTE Proprietary sentences: PGRMZ Transmission rate: GPBWC, GPGLL, GPRMB, GPRMC, GPXTE, and PGRMZ transmitted once every two seconds. GPR00 transmitted once every (# of all waypoints + 1) * 2 seconds.

  • Page 96: C.2 Electrical Wiring

    · Connect the BLACK harness lead to the negative (-) side of the 5-40 volt DC power source. The GPS 95 will drive a remote alarm or relay that requires no more than 100 milliamps of current. (WARNING: Devices which draw current in excess of 100 milliamperes may damage your unit and will void your warranty.

  • Page 97: C.3 Yoke Mount Installation

    Generally, the standard clamp will not fit the following: Bonanza/Baron, Commanche, large Piper twins, and some other large Beech models. The GPS 95 can also be fix mounted to a surface using the surface mount. Before permanent mounting, you may wish to apply power to the unit and look at the display in the desired mounting location to ensure you have the desired viewing angle.
  • Page 98 To attach the yoke mount to the control yoke... · Loosen the lower knob. · Slide the clamp over the control yoke shaft just behind the control wheel. · Tighten the lower knob securely. · Make sure that the clamp is as close as possible to the control wheel and check to make sure that the yoke travel is not limited or hindered in any way by the yoke mount.

  • Page 99: C.4 Yoke Mount Operation

    C.4 YOKE MOUNT OPERATION The yoke mount has been designed for easy insertion and removal of your GPS 95 if you wish to use the unit in another airplane or vehicle, to plan at home, or to prevent theft.
  • Page 100 To insert the GPS 95 into the yoke mount... · Tilt the top of the GPS 95 into the yoke mount as shown. · Engage the slot in the top of the GPS 95 into the raised bump in the yoke mount bracket.

  • Page 101: C.5 Portable Antenna Installation

    · Apply enough force to the release tab to allow the unit to pass as shown above. · Pull the bottom of the GPS 95 out. Then rotate the top downward and out. NOTE: The portable antenna is removed by gripping the antenna at its base (on the knurled knob) and rotating 1/4 turn counterclockwise.
  • Page 102 To replace the alkaline batteries... · Grip the battery pack around the outside edge (not the bottom). · Push the top of the battery pack against the edge of a hard surface which will not mar the plastic. The outer sleeve will slide off the cage, revealing the batteries inside.

  • Page 103: C.7 Maintenance

    “Memory Battery Low”. You should return your unit to an authorized GARMIN service center as soon as possible for service. Failure to do so may result in loss of data each time you turn your unit off (indicated by the message “Stored Data Lost”).

  • Page 104: D Map Datums

    The following is a list of the GPS 95 map datum selections and the corresponding map datum name (including the area of application): Adindan Afgooye AIN EL ABD 1970 Anna 1 Astro 1965 ARC 1950 ARC 1960 Ascension Island ‘58 Astro B4 Sorol Atoll Astro Beacon “E”...
  • Page 105 Geodetic Datum ‘49 Guam 1963 Gux 1 Astro Hjorsey 1955 Hong Kong 1963 Indian Bangladesh Indian Thailand Ireland 1965 ISTS 073 ASTRO ‘69 Johnston Island Kandawala Kergulen Island Kertau 1948 L.C. 5 Astro Liberia 1964 Luzon Mindanao Luzon Philippines Mahe 1971 Marco Astro Massawa Merchich...
  • Page 106 Nahrwn Saudi Arbia Nahrwn United Arab Naparima BWI Observatorio 1966 Old Egyptian Old Hawaiian Oman Ord Srvy Grt Britn Pico De Las Nieves Pitcairn Astro 1967 Prov So Amricn ‘56 Prov So Chilean ‘63 Puerto Rico Qatar National Qornoq Reunion Rome 1940 RT 90 Santo (Dos)
  • Page 107 UTC TIME TO LOCAL TIME OFFSET Reference the chart below to find the UTC-to-local time offset for your longitude zone. (If you are in a daylight savings time zone, add one hour to the offset.) For example, if you are at longitude W081°00.00' and UTC time is 16:00, local time is 11:00 standard time.
  • Page 108 Crosstrack error (XTK) Cursor Cyclic field Data, entering Date/Time Page 8-11 Density altitude 8-11 Desired track (DTK) Differential GPS (DGPS) Dilution of precision (DOP) Display contrast Distance to waypoint (DIS) DTK up E6-B calculations 8-12 ENT Key Entering data Estimated position error...
  • Page 109 Fuel planning Filters, setting GARMIN input/output GOTO, activating GOTO, cancelling GOTO function GOTO Key GPS status Ground speed (GS) Heading, selecting Initial position, defining Interface Page Interface, selecting Keypad Local time Local time, offset Maintenance Map Configuration Page Map Datum Page...
  • Page 110 Reviewing waypoints Route Definition Page Route List Page Routes activating copying creating deleting editing inverting RTCM input RTE Key Satellite Skyview Page Satellite Status Page Scale, map Scanning waypoints Setups, unit Simulator mode Softkeys Specifications Steer to, orientation Sunrise/Sunset Page 3D Navigation Timer, count down Timer, count up...
  • Page 111 GARMIN International, Inc. 9875 Widmer Road Lenexa, KS 66215 1-800-800-1020 (913) 599-1515 190-00054-00 Rev. A...
