  • Page 1 Control System - ICS Direct Wheel Control Translation of the Original Instructions _7225 2018-04-22 2200401...
  • Page 2 Declaration of conformity for the incorporation of a partly-completed machine. In accordance with Machinery Directive 2006/42/EC. Appendix II B. Rototilt Group Systems AB Box 56 SE-922 21 Vindeln SWEDEN declare under our sole responsibility that the following product: ICS Direct Wheel...
  • Page 3 Overview The product described in the document consists of components for the ICS Direct wheel control system. The overviews show standard equipment and options. Refer to the illustrations and lists below and on the following pages. ICS Direct is design to facilitate the movement of the base machine/excavator when working. ICS Direct wheel control is manoeuvred using switches and or rollers in the handles.
  • Page 4: Control Unit

    Alternative alternative control is installed on the base steering inactive machine/excavator. ICS Direct When ICS Direct is activated the lamp activated lights. When the operation inhibitor is activated the lamp flashes to warn that the system is switched off. © Rototilt Group AB...
  • Page 5 IMPORTANT - The base machine/excavator’s factory excavator. mounted handles have been replaced with handles adapted for ICS Direct. Carefully check the changed functions, for both the base machine/excavator and alternative control. © Rototilt Group AB 2200401_...
  • Page 6: Operation

    Steering (left and right) with the left-hand handle. Deactivate Warning Flashing light ICS Direct is deactivated as follows: Sound 3 sec. 5. Switch off alternative control with the switch in the handle. The control system's indicator lamp goes out to indicate that alternative control is deactivated.
  • Page 7: Alternative Connection

    - If the voltage to the base machine/excavator fails, the base machine/excavator must first be driven at a ICS Direct Wheel control can also be low speed so that the system can be reactivated. connected to a frequency sensor in the base machine/excavator’s transmission.
  • Page 8: Detailed Troubleshooting

    Troubleshooting ICS Direct The control unit has two diodes and a buzzer, which indicate how the control system is working. The components light and sound at different intervals and combinations. The components are controlled by the signals that pass between the control unit and the other parts of the control system.
  • Page 9: Input Signal

    Check the harness in terms of crush slowly. at the pressure sensor. damage or open circuit. same rate as • Check the sensor the green LED. • Contact the service workshop. © Rototilt Group AB 2200401_ _7225 2018-03-26 English EN - trouble:2...
  • Page 10: Output Signal

    • Restart the control system. the green • Contact the service workshop. LED. To reset the fault indication, restart the system by disconnecting the voltage on the base machine. © Rototilt Group AB 2200401_ _7225 2018-03-26 English EN - trouble:3...
  • Page 11 4. Port LSO 5. Port A 6. Port B 7. Connector 3 8. Connector 4 9. Connector 2 10. Pressure Sensor, PT 11. Port EF 12. Port LSP 13. Pressure Relief © Rototilt Group AB 2200401_ _7225 2018-04-27 English EN - schema:1...
  • Page 12 Valveblock, Wheel Control - Open Center ICS Direct Wheel Control can be adapted with two alternative options for Valve Block. Both Valve Blocks are connected to the same functions for the system. Illustration below shows the Open Center Version. Open Center ©...
  • Page 13 Valveblock, Wheel Control - Static / Dynamic ICS Direct Wheel Control can be adapted with two alternative options for Valve Block. Both Valve Blocks are connected to the same functions for the system. Illustration below shows the the Static / Dynamic Version.
  • Page 14 Hydraulic connections, Open Center P IN PLUG HOSE ⁄ ” HOSE ¼” ADAPTER BYPASS © Rototilt Group AB 2200401_ _7225 2018-04-27 English EN - schema:4...
  • Page 15 Hydraulic connections, Static / Dynamic P IN HOSE ⁄ ” HOSE ¼” ADAPTER BYPASS © Rototilt Group AB 2200401_ _7225 2018-04-27 English EN - schema:5...
  • Page 16 Harness ICS Direct General version © Rototilt Group AB 2200401_ _7225 2018-04-27 English EN - schema:6...
  • Page 17 Harness, Pressure Sensor © Rototilt Group AB 2200401_ _7225 2018-04-27 English EN - schema:7...
