Control System - TLEE Closed
R4
Instructions for use - translated from the original Swedish
2200256_6361 2017 01 18 | ML

Advertisement

loading
Need help?

Need help?

Do you have a question about the TLEE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ROTOTILT TLEE

  • Page 1 Control System - TLEE Closed Instructions for use - translated from the original Swedish 2200256_6361 2017 01 18 | ML...
  • Page 2: Control Unit

    Also refer to the relevant hydraulic diagram. In contrast to TLE and TLEX systems, TLEE and TLEEX control systems have two extra hydraulic connections. The systems have the following components fitted in the base machine.
  • Page 3 Rototilt® is hydraulically connected to the base machine by two separate, double-acting circuits. by switches in the handle or by foot pedal. Functions; rotation, tilt, extra, extra 2 (TLEE) and The Extra functions allow the use of a hydraulic quick coupler locking function.
  • Page 4 Switch and buzzer for the quick coupler locking function The switch (1) activates the quick coupler locking function control valve on Rototilt® to the open or closed position. The blocking function locks the switch in the open position and the blocking function should prevent unintentional activation of the function.
  • Page 5 Rototilt® is disconnected. For the base machine’s quick coupler locking function to work, the contact to Rototilt® must then be replaced with the safety plug. © Rototilt Group AB 2017-01-18 English...
  • Page 6 The audible warning will cease and the light goes out. The directional valve for the quick coupler locking function on Rototilt® now returns to the position for closing the lock. To extend the locking cylinder, Rototilt® must be pressurized...
  • Page 7 Valveblock, Swivel R4 1. Option/Extra2 2. Grapple/Extra 1 3. Coupler Control Unit TLEE 1. Red light - Rototilt® in “standby” mode 2. Yellow light #1 - Input signal from switch for the selected function 3. Green Light - Output signal from the selected function.
  • Page 8 Hydraulic Schematic TLEE Closed R4 © Rototilt Group AB 2017-01-18 English SCHEMATICS - TLEE Closed...
  • Page 9 Schematic El System - TLEE Closed Machine © Rototilt Group AB 2017-01-18 English SCHEMATICS - TLEE Closed...
  • Page 10 Schematic El System - TLEE Closed R4 LOCKING CYLINDER SEPARATE GROUND, LOCKING CYLINDER COMMON GROUND, TILT, EXTRA & EXTRA2 © Rototilt Group AB 2017-01-18 English SCHEMATICS - TLEE Closed...
