Tellabs® ONT205 Installation and Turnup Guide
Introduction
This guide describes the Tellabs FlexSym ONT205 optical network terminal (ONT), its
features, specifications, status indicators and installation.
The FlexSym ONT205 is part of the Tellabs 1600 series of XGS-PON ONTs for passive
optical networks (PON). It is a compact desktop unit that also be mounted to most
surfaces using a wall mount bracket (optional). The FlexSym ONT205 is also plenum
rated for above ceiling applications.
When connected to a Tellabs 1100-series optical line terminal (1150/1150E, 1134, 1131,
OLT6, FlexSym OLT6, FlexSym OLT-mini) through a single fiber optic cable, the ONT
provides high-performance enterprise features, combined with cost, energy, and space
savings, all within the Tellabs exclusive high-security All Secure™ PON.
Document Revisions
Revision Date
November
Revision A
2019
Revision B January 2020
Intended Audience
This document is intended for technicians responsible for:
• Preparing the install location
Initial Release
Update to Description, PoE Table
Page 4 of 38
