9.0 Installation of Double Platform

Before the installation of double platform, turn off the POWER switch.
For installation of double platform, prepare upper platform with rubber pad and posts kit, which
includes four posts, four washers, four screws and four nuts.
Posts kit
E
A
B
C
1. Set four posts (A) above four holes at the corners of the bottom platform.
2. Put the washer (B) on each screw (C) and then screw it into each post from the bottom side
of the platform.
3. Fit upper platform (D) on the top of four posts, so that the threads of the posts are protruding through
four corner holes.
4. Screw four nuts (E) on the threads of four posts, to fix the upper platform.
E
D
A
B
C
