GVision K17TH-F Specifications

1 7 " O p e n F r a m e T F T L C D M o n i t o r
Industrial Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Input Signals
Signal Connector Analog
Digital
Video-in
Scan Frequency
Speakers
USB HUB
Touch panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions (WxHxD)
Dimensions (Carton 2 in 1)
Weight (Net)
Certification
* Specifications are subject to change without notice.
I/O Ports
UNOT : mm
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s F l e x i b i l i t y F l e x i b i l i t y
K17TH-FA
17" TFT active matrix panel
0.264(H) x 0.264 (V) mm
SXGA 1280 x 1024
450:1 (typical)
2
250 Cd/m (typical)
16 ms (typical)
16M
337.9 (H) x 270.3 (V)
140 (H) x 140 (V)
CCFL x 4
40,000(hr)
Analogue VGA
D-sub 15 pin (VGA)
DVI-D (Option)
RCA, S-video (Option)
H. scan 31 ~ 80 KHz,
V. scan 56 ~ 75Hz
N/A
N/A
Resistive/Capacitive - RS232 or
USB A type (Option)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
0 C-50 C (32 F-122 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% (no condensation)
Universal power adaptor
Input AC 100~240V, 50~60Hz;
Output DC 12V / 4A
48W
VESA DPMS Standard
439.5 x 337.5 x 51 mm
505 x 470 x 190 mm
7.2 Kg
C-UL, FCC, CE
Mechanical drawing
Audio L Audio R Video
Front Side
Featires :
* High contrast color TFT LCD open frame display support
resolution up to SXGA 1280x1024. Compatible with IBM,
VGA, VESA standards.
* Flexible mechanical designs for industrial application.
* Multi-signals: VGA, DVI, Composite video, s-video (Auto
detection of input signals).
* Composite video system PAL/NTSC and SECAM
compatible.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Optional touch solutions.
* Flexible Mounting Solutions - Front mounting, Racking
mounting & VESA mounting.
* Optional Industrial Power Plug.
* Hot key for AUTO adjustment.
* Space reserved under I/O port.
Optional Accessories :
• 3M 5 Wire resistive touch panel
• 3M Capacitive touch panel
• ELO 5 Wire resistive touch panel
• Anti-Glare tempered glass
• Customized touch solution acceptable.
• Front Mounting Frame.
• 19" Rack Mounting Frame.
• Built-in Industrial Power Plug
Ordering Information :
• K17TH-FA
• K17TH-FW
• K17TH-FB
• K17TH-FE
S-Video DVI VGA DC in Touch
Back Side
K17TH FA K17TH FA K17TH-FA
VGA only
VGA + Video-in
VGA + DVI
VGA + DVI + Video-in
