GVision K15PX-F Specifications

1 5 " T F T L C D M o n i t o r
Industrial Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio*
Brightness*
Response Time* ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Input Signals
Signal Connector Analog
Digital
Video-in
Scan Frequency
Speakers
USB HUB
Touch panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions (WxHxD)
Dimensions (Carton 2 in 1)
Weight (Net)
Certification
* Specifications are subject to change without notice.
OPEN FRAME
UNOT : mm
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s F l e x i b i l i t y F l e x i b i l i t y
K15PX-FA
15" TFT active matrix panel
0.297(H) x 0.297 (V) mm
XGA 1024 x 768
400:1 (typical)
2
250Cd/m (typical)
16ms (typical)
16M
304(H) x 228(V)
120 (H) x 100 (V)
CCFL x 2
40,000(hr)
Analogue VGA
D-sub 15 pin (VGA)
N/A
RCA, S-video (option)
H. scan 31~60KHz,
V. scan 60 ~ 75Hz
N/A
N/A
Resistive/Capacitive - RS232 or
USB A type (option)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
0 C-50 C (32 F-122 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Imbedded AC Input ,Universal
100~240V
48W
VESA DPMS Standard
397.3 x311.0 x 57.0 mm
480 x 452 x 261 mm
5.3 Kg
C-UL, FCC, CE
Mechanical drawing
I/O Ports
Option Audio
Features :
* High contrast color TFT LCD open frame display support
resolution up to XGA 1280x 768. Compatible with IBM
VGA, VESA standards.
* Flexible mechanical designs for industrial application.
* Multi-signals: VGA, Composite video, s-video (Auto
detection of input signals).
* Composite video system PAL/NTSC and SECAM
compatible.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Optional panel mounting solution.
* Optional touch solutions.
* Built-in power
Optional Accessories :
* 3M 5 Wire resistive touch panel
* 3M Capacitive touch panel
* ELO 5 Wire resistive touch panel
* Anti-Glare tempered glass
* Customized touch solution acceptable.
Ordering Information :
OPEN FRAME
* K15PX-FA VGA only
* K15PX-FW VGA + Video-in
PANEL MOUNT
* K15PX-HA VGA only
* K15PX-HW VGA + Video-in
VG A Touch AC in
PANEL MOUNT
K15PX FA K15PX FA K15PX-FA
