U-Line S-15179 Quick Start Manual

S-15179
3-5 SUIT SHIPPER
1. Fold corrugated tabs in the bar cutout toward the
inside of the box. (See Figure 1)
Figure 1
2. Take the bar and remove the clip. (See Figure 2A)
3. Slightly bend cover and lift off the bar. (See Figure 2B)
Figure 2
A
4. Hang suits/garments on hangers and place the
hangers on the bar. (See Figure 3)
Figure 3
PAGE 1 OF 3
1-800-295-5510
uline.com
ASSEMBLY
B
5. Slightly bend cover and place back on the bar to
secure hangers in place. Place the clip back on.
(See Figure 4)
Figure 4
6. Insert the garments inside the box and secure the
bar inside of cutouts. (See Figure 5)
Figure 5
Para Español, vea página 2.
Pour le français, consulter la page 3.
0721 IS-15179
