U-Line S-24269 Quick Start Manual

S-24269, S-24270
HANGING SAFETY SHIELD
Safety Shield x 1
1. Thread end of cable through hole on the shield and
pass it through end loop. (See Figure 1)
Figure 1
2. Thread cable through one of the holes on the cable
adjuster, in direction indicated by marked arrows.
(See Figure 2)
Figure 2
PAGE 1 OF 3
1-800-295-5510
uline.com
PARTS
10' Cable x 2
ASSEMBLY
3. Pass cable around any
supporting structure on
ceiling. (See Figure 3)
4. Thread cable through
the other hole on cable
adjuster. Height of shield
can be determined by
pulling cable through
adjuster as needed.
(See Figure 4)
NOTE: To raise or lower
shield, press button
on cable adjuster
to release locking
mechanism. Hold
shield while releasing
mechanism to prevent
it from falling.
(See Figure 5)
Para Español, vea página 2.
Pour le français, consulter la page 3.
Cable Adjuster x 2
Figure 3
Figure 4
Button
Figure 5
0421 IS-24269
