S-5188, S-9924
CORRUGATED
BALLOT BOX
1.
Fold the bottom flaps in, following the numbers 1-4.
(See Figure 1) After folding flap 4, allow all flaps to
spring back into locked position.
Figure 1
2. Stand the box upright and fold in the top side
flaps. Close the lid. Fold the locking tab into
corresponding slot. (See Figure 2)
Figure 2
PAGE 1 OF 3
1-800-295-5510
uline.com
ASSEMBLY
4
2
3
1
3. If optional header is used, insert the header into
appropriate slots. (See Figure 3)
Figure 3
Para Español, vea página 2.
Pour le français, consulter la page 3.
0724 IS-5188
