ASSEMBLY INSTRUCTION FOR MAXI ULTRA-515
When attaching unit to wall put safety bracket in middle of
unit with 16mm pan head screw then 25mm pan head screw
into wall. For plasterboard without a stud it is recommended
to use a plug with screw (not provided).
2 x L & R GABLES
1 x BACKING BOARD
3 x FIXED SHELF
NO MODEL
DESCRIPTION
CONFIRMAT SCREWS 50mm x 5mm
1
2
CAPS
3
BACKING NAILS
4
SUPPORT PINS
TOP of UNIT
A
F
G
FOLD LINE
C ,D & E
1 x ADJUSTABLE SHELF
1 x BOTTOM KICK
QTY
NO MODEL
5
20
20
6
75
7
4
H
B
DESCRIPTION
16mm PAN HEAD SCREWS
25mm PAN HEAD SCREWS
"L" SAFETY BRACKET
QTY
1
1
1
