We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Contents
4
4
8
8
8
8
8
9
10
10
11
11
12
13
13
14
15
15
16
17
23
23
25
27
32
32
32
33
34
35
36
37
38
40
40
45
47
3
Advertisement
Table of Contents
Related Manuals for Smeg Selezione Concerto Series
Summary of Contents for Smeg Selezione Concerto Series
-
Page 1: Table Of Contents
5 Installation 5.1 Positioning 5.2 Electrical connection 5.3 Instructions for the installer We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com... -
Page 2: Instructions
Instructions 1 Instructions • Cleaning and maintenance must not be carried out by 1.1 General safety instructions unsupervised children. Risk of personal injury • Be aware of how rapidly the cooking zones heat up. Do not • During use the appliance and its place empty pans on the heat. - Page 3 Instructions • If you need to move food or at the • Have qualified personnel carry out end of cooking, open the door 5 cm installation and assistance for a few seconds, let the steam interventions according to the come out, then open it fully. standards in force.
- Page 4 Instructions • Do not obstruct ventilation • Do not use the open door to rest openings and heat dispersal slots. pans or trays on the internal glass pane. • Never leave the appliance unattended during cooking • Cooking vessels or griddle plates operations where fats or oils should be placed inside the could be released, as these could...
- Page 5 Instructions • Do not use steam jets to clean the • To avoid potential overheating, the appliance. appliance must not be installed behind a decorative door or a • Do not use rough or abrasive panel. materials or sharp metal scrapers. •...
-
Page 6: Manufacturer's Liability
Instructions • Do not use the glass ceramic 1.4 Identification plate cooking surface as a support The identification plate bears the surface. technical data, serial number and • Ensure that the appliance is brand name of the appliance. Do not switched off before replacing the remove the identification plate for bulb. -
Page 7: To Save Energy
Instructions To dispose of the appliance: 1.7 To save energy • Cut the power supply cable and • Only preheat the appliance if the remove it along with the plug. recipe requires you to do so. • Unless otherwise indicated on the Power voltage package, defrost frozen foods Danger of electrocution... -
Page 8: How To Read The User Manual
Instructions 1.8 How to read the user manual This user manual uses the following reading conventions: Instructions General information on this user manual, on safety and final disposal. Description Description of the appliance and its accessories. Information on the use of the appliance and its accessories, cooking advice. -
Page 9: Description
Description 2 Description 2.1 General Description 1 Cooking hob 5 Door 2 Control panel 6 Fan 3 Oven light 7 Storage compartment 4 Seal Rack/tray support frame shelf... -
Page 10: Cooking Hob
Description 2.2 Cooking hob Max. absorbed power Absorbed power in Zone Dimensions (H x L - mm) (W)* Booster function (W)* 180 x 180 1850 2100 145 x 145 1200 1400 180 x 180 1850 2100 145 x 145 1200 1400 * power levels are indicative and can vary according to the pan used or the settings made. -
Page 11: Control Panel
Description 2.3 Control panel 1 Function knob 2.4 Other parts The oven's various functions are suitable for Oven shelves different cooking modes. After selecting the The oven features shelves for positioning required function, set the cooking trays and racks at different heights. The temperature using the temperature knob. -
Page 12: Available Accessories
Description Interior lighting Deep tray The oven interior lighting comes on when the door is opened or any function is selected, except for the functions. 2.5 Available accessories Original and optional accessories can be requested to Authorised Assistance Centres. Use only Useful for collecting fat from foods placed original accessories supplied by on the rack above and for cooking pies,... -
Page 13: Use
3 Use Improper use Risk of damage to surfaces 3.1 Instructions High appliance temperature • Do not cover the bottom of the oven with during use aluminium or tin foil sheets. Danger of burns • If you wish to use greaseproof paper, place it so that it will not interfere with the •... -
Page 14: Using The Accessories
Oven cavity High temperature inside the storage compartment during use 4. Heat the empty oven at the maximum temperature to burn off any residues left Danger of fire or explosion by the manufacturing process. • Do not spray any spray products near 3.2 Using the accessories the oven. -
Page 15: Using The Hob
Tray rack Cookware suitable for use in induction cooking The tray rack has to be inserted into the tray. In this way fat can be collected separately Cookware used on the induction cooking from the food which is being cooked. surface must be made of metal, with magnetic properties and a sufficiently large base. - Page 16 Cookware recognition If the symbol appears on the display, it means the pan is not suitable. When there is no saucepan on a cooking zone or if the saucepan is too small, no energy will be transmitted and the symbol will appear on the display. If there is a suitable saucepan on the cooking zone, the recognition system detects it and switches on the hob to the...
- Page 17 Limiting the cooking duration Power levels The hob has an automatic device which The power in the cooking zone can be limits the duration of use. adjusted to various levels. The table shows the levels suitable for various types of If the cooking zone settings are not cooking.
- Page 18 Switching off the cooking zone Press key to deactivate the Power 1. Select the cooking zone you wish to function. switch off using the zone selection keys. On the front left and rear right 2. Use the key to bring the power cooking zones only: value to 0 (zero).
- Page 19 buzzers. Press any key to stop the 4. Press keys at the same time buzzer. until a lighted dot appears under the display of the zone whose set time you To deactivate the minute minder wish to change. Once the relevant zone timer during the countdown, zero is selected, use keys the set time using key...
- Page 20 Cooking guidelines Setting the hob power limit The table below shows the power values The induction hob is configured to which can be set, together with the operate at 7 kW. However, the corresponding type of food. Settings may maximum power can be limited so vary depending on the amount of food and that it can work at 4.5 kW or 3.1 consumer taste.
-
Page 21: Using The Storage Compartment
Examples of possible combinations 3.4 Using the storage compartment based on the set power The storage compartment is at the bottom of the cooker. To open it, pull the handle Power Plate Plate Plate Plate towards you. It can be used to store (kW) 210 LH 180 LH... - Page 22 Grill Fan-assisted bottom The heat coming from the grill The combination of the fan with just element gives perfect grilling results the lower heating element allows above all for thin and medium cooking to be completed more thickness meat and in combination rapidly.
-
Page 23: Cooking Advice
3.6 Cooking advice This function is particularly suitable General advice for cooking on a single shelf with • Use a fan-assisted function to achieve low energy consumption. uniform cooking at several levels. It is recommended for all types of • It is not possible to shorten cooking times food except those that may by increasing the temperature (the food produce a large amount of moisture... - Page 24 • Foods should be seasoned before Advice for defrosting and proving cooking. Foods should also be coated • Place frozen foods without their with oil or melted butter before cooking. packaging in a lidless container on the • Use the oven tray on the first bottom shelf first shelf of the oven.
-
Page 25: Programmer Clock
3.7 Programmer clock Setting the time If the time is not set, the oven will not switch on. On the first use, or after a power failure, the digits will be flashing on the appliance’s display. 1. Hold down the clock button two seconds. - Page 26 Timed cooking 7. Press the clock button to reset the programmer clock. Timed cooking is the function which allows a cooking operation It is not possible to set a cooking to be started and then ended after time of more than 10 hours. a specific length of time set by the user.
- Page 27 10. Return the function and temperature 4. Press the button to set the knobs to 0. required minutes. (for example 1 hour). 11. To turn off the buzzer just press any 5. Press the menu button . The text button of the programmer clock. will appear on the display in 12.
- Page 28 Modifying the set data Minute minder timer 1. Press the clock button The minute minder timer does not stop the cooking operation but 2. Use the value increase and value rather informs the user when the set time has run out. decrease buttons to set the number of minutes required.
- Page 29 Cooking information table Weight Temperature Time Food Function Shelf (Kg) (°C) (minutes) Lasagne 3 - 4 Static 220 - 230 45 - 50 Pasta bake 3 - 4 Static 220 - 230 45 - 50 Veal roast Turbo/Circulaire 180 - 190 90 - 100 Pork loin Turbo/Circulaire...
-
Page 30: Cleaning And Maintenance
Cleaning and maintenance 4 Cleaning and maintenance 4.2 Cleaning the surfaces To keep the surfaces in good condition, 4.1 Instructions they should be cleaned regularly after use. Let them cool first. Improper use Risk of damage to surfaces Ordinary daily cleaning Always and only use specific products that •... -
Page 31: Cleaning The Hob
Cleaning and maintenance 4.3 Cleaning the hob Weekly cleaning Clean and maintain the hob once a week Cleaning the glass ceramic hob using an ordinary glass ceramic cleaning Light coloured marks from pans with product. Always follow the manufacturer’s aluminium bases can be easily cleaned off instructions. -
Page 32: Removing The Door
Cleaning and maintenance 4.4 Removing the door 3. To reassemble the door, put the hinges in the relevant slots in the oven, making sure For easier cleaning it is recommended to that grooved sections A are resting remove the door and place it on a tea completely in the slots. -
Page 33: Removing The Internal Glass Panels
Cleaning and maintenance 4.5 Removing the internal glass 4. Clean the external glass panel and the panels panels previously removed. Use absorbent kitchen roll. In case of For easier cleaning the door internal glass stubborn dirt, wash with a damp sponge panels can be disassembled. -
Page 34: Cleaning The Oven Cavity
Cleaning and maintenance 4.6 Cleaning the oven cavity Cleaning the racks and trays In order to keep your oven in the best Clean the racks and trays with warm water possible condition, clean it regularly after and non-abrasive detergents. Carefully letting it cool down. -
Page 35: Pyrolysis
Cleaning and maintenance 4.7 Pyrolysis Setting up the pyrolytic function 1. Turn the function knob to the Pyrolysis is an automatic high- temperature cleaning procedure symbol. Will appear on the which causes dirt to dissolve. display alternating with the minimum Thanks to this process, it is possible pyrolytic cycle time (2 hours). -
Page 36: Extraordinary Maintenance
Cleaning and maintenance 8. Wait for the oven to cool down and During the pyrolytic cycle the fans collect the residues deposited inside produce a more intense level of with a damp microfibre cloth. noise due to a greater rotation speed. - Page 37 Cleaning and maintenance 3. Remove the bulb cover using a tool (e.g. a screwdriver). 4. Slide out and remove the lamp. Do not touch the halogen lamp directly with your fingers, but wrap it in an insulating material. 5. Replace the lamp with one of the same type (40W).
-
Page 38: Installation
Installation 5 Installation Any wall units positioned above the worktop of the appliance must be at a 5.1 Positioning minimum distance of at least Y mm. If a hood is installed above the hob, refer to the Heavy appliance hood instruction manual to ensure the Crushing hazard correct clearance is left. - Page 39 Installation Appliance overall dimensions 600 mm 600 mm B - Class 2 subclass 1 min. 150 mm (Built-in appliance) 900 - 915 mm 750 mm 450 mm 600 mm Minimum distance from side walls or other flammable material. Minimum cabinet width (=A). C - Class 2 subclass 1 (Built-in appliance) The appliance must be installed by...
- Page 40 Installation Dimensions of the appliance: locations of Positioning and levelling gas and electric connections (mm) Heavy appliance Risk of damage to the appliance • Insert the front feet first and then the rear ones. • After making the gas and electrical connections, screw on the four feet supplied with the appliance.
- Page 41 Installation 3. Assemble the fastening bracket. Fastening to the wall The anti-tip devices must be installed in order to prevent the appliance from tipping over. 1. Screw the wall fastening plate to the rear of the appliance. 4. Align the base of the hook on the fastening bracket with the base of the slot on the wall fastening plate.
- Page 42 Installation 5. Align the base of the fastening bracket 7. Move the bracket onto the wall and with the ground and tighten the screws mark the position of the holes to be to fix the measurements. drilled in the wall. 6.
-
Page 43: Electrical Connection
Installation 5.2 Electrical connection The appliance can work in the following modes: Power voltage • 220-240 V 2~ Danger of electrocution • Have the electrical connection performed by authorised technicians. • Use personal protective equipment. 3 x 10 mm² three-core cable. •... - Page 44 Installation Access to the terminal board The aforementioned power cables are sized taking into account the To connect the power supply cable, access coincidence factor (in compliance to the terminal board on the rear cover: with standard EN 60335-2-6). 1. Remove the screws securing the lid to the rear cover.
-
Page 45: Instructions For The Installer
Installation 4. At the end, reposition the lid on the rear cover and secure it with the previously removed screws. 5.3 Instructions for the installer • The plug must be accessible after installation. Do not bend or trap the power cable. •...
