Cables and Connectors

This table provides detailed information about the cables and connectors used by the
UP Squared 6000 (UPN-EHL01). If you have any questions about the configuration of
your board, please contact your AAEON sales representative.
Loca-
Connector
tion
SW1 1601000990
CN28 1655X00019
CN35 1654207536
CN36 1654207533
CN38 1654801832
CN39 1654907009
CN40 1655302025
CN41 16528X0015
CN43 1654403931
CN44 16522X0031
CN48 165420753B
CN49 1655X00031
Appendix B – Cables and Connectors
Function Description
PWR button
RTC
M.2 Key-B Slot
M.2 Key-E Slot
USB Type A
DUAL PORT
SATA CONN
SATA POWER
LAN DUAL PORT
HDMI + DP
HAT 40
M.2 Key-M Slot
USB 2.0/UART 1x10P
Wafer
Mating
Cable PN/ Mating Cable Description
CONN PN
Lithium
Battery.CR2032H.3V.240mAH.
175011301K
w/cable 90mm.DIP .Battery
power.BP-CR2032-M90-001
(TF)SATA CABLE.7P Pitch
1709070500
1.27mm.50cm
(TF)Power Cable.15P
SATA(F).2P 2.0mm
Housing(PH).15cm
1702150155 (TF)SATA CABLE.7P Pitch
1702150306 1.27mm.50cm
(TF)Power Cable.15P
SATA(F).2P 2.0mm
Housing(PH).30cm
38
