GALLERY SERIES LED LUMINAIRES QUICK START GUIDE GALLERY_QUICK_START_20220114...
Page 2
Note: Information contained in this document may not be duplicated in full or in part by any person without prior written approval of Altman Lighting Its sole purpose is to provide the user with conceptual information on the equipment mentioned. The use of this document for all other purposes is specifically prohibited.
Gallery Series Quick Start Guide Important Information Product Safety Notices When using electrical equipment, basic safety precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS. Do not use outdoors unless the product is specified to operate in outdoor environments.
Altman Lighting, Inc., a subsidiary of Altman Stage Lighting Company, Inc., herein referred to as Altman, war- rants each new product (except for spare parts or products Altman does not manufacture) for a period of FIVE (5) years and ONE (1) day from date of shipment to correct by repair or replacement any part defect due to faulty material or workmanship.
Gallery Series Quick Start Guide Table Of Contents Important Information Altman Lighting Product Warranty Table Of Contents Installation & Set Up Top Box Overview Gallery Gate Installation Gallery Lens Installation Safety Cable Installation Power Requirements Connecting Power Mains Dimming Version...
Gallery Series Quick Start Guide Installation & Set Up Top Box Overview There are several mounting configurations for the Gallery Series LED Luminaires: • Portable - C-Clamp / Unistrut • Smart Track / Track • Ceiling / Pendant The model(s) purchased determines how the unit can be mounted. Figure 5 shows the features and connections on the two versions of the Gallery Series Luminaire top boxes.
Gallery Series Quick Start Guide Gallery Gate Installation The provided Gallery Gate should be installed as shown in Figure 2. Note: The Gallery Gate is only supplied and required for the 25°- 50° Short Zoom Lens and 15°- 35° Long Zoom...
Power Requirements WARNING! The Gallery Series LED Luminaires should be connected to a constant circuit or a relay device. It should never be connected to a dimmer or circuit controlled by a dimmer unless the unit is specifically designed to do so (MAINS dimming models - 120VAC only).
Quick Start Guide Mains Dimming Version Gallery Series LED Luminaires are available in a 120VAC Mains Dim version which is achieved with standard TRIAC-Based incandescent dimmers (see Table 2, “Compatible Mains Dimmers,” on page 11) that “chop” the AC voltage or with standard ELV (electronic low-voltage) dimmers.
Remote top box models must be ordered specifically as a remote top box set up. Remote top box units have a one (1) meter cable between the luminaire engine and top box. Refer to the Altman Lighting web site www.altmanlighting.com for more details.
Quick Start Guide 0-10V Controlled Models (Sink Current) Gallery Series LED Luminaires’ 0-10V drivers only operate with dimmers that sink current. They are not de- signed to operate with 0-10V controls systems that source current, as used in theatrical and entertainment systems.
To wire and install canopy / pendant mounted models: Step 1. Install Gallery Series LED Luminaires Mounting Flange to ceiling junction box. Ceiling junction box is octagon-style box (by others). Mounting hole spacing is 3.5-inches (88.9 mm).
From the DMX OUTPUT of the luminaire another cable runs to the DMX IN connection on the next luminaire or other DMX512 device to be controlled. At the end of each DMX Daisy chain, it is highly recommended that a DMX TERMINATOR (Altman Lighting part number DMX-MPHX-TERM for the connectors shown in Table 2) is utilized on the last luminaire (or device) in the chain.
Gallery Series Quick Start Guide Terminal Block (Phoenix Connector) Wiring • All pin information is read from left to right from the back of the connector (looking at wiring inlet). • (DMX Version Ceiling mount) One (1) piece of Category 5 Belden 1592A cable for all data connec- tivity.
Quick Start Guide Setting a DMX Address via RDM Gallery Series LED Luminaires are full featured Remote Device Management (RDM) compliant. All DMX and Luminaire settings are programmed via a RDM ANSI E1.20 complaint device. As many of the RDM devices and software work differently please consult the RDM programmer manufacturer for specific operational instructions.
Note: Any change in the DMX value will over ride the focus button (last action takes precedence). Zoom Spot Models Gallery Series LED Luminaires fitted with a short or long zoom lens, has the following features: • User-settable and lockable zoom and focus control •...
Page 17
Gobo Slot Gallery Series LED Luminaires with zoom spot lenses offer a gobo slot (Figure 15) to hold one E-size gobo with the dimensions of 37.5 mm OD with a 28 mm image area. Gobo holder is included with all zoom spot models and can be purchased as an additional accessory.
Page 18
Beam Angle Adjustment Gallery Series LED Luminaires that have the beam wash lens are designed and are ideal to project a soft edge, even beam of light. For beam wash models, beam shaping is achieved through external, four-flap barn doors (sold separately).
Page 19
Pan & Tilt - All Models All Gallery Series LED Luminaires can have their pan and tilt set by hand (without the use of tools). To adjust pan or tilt, loosen (do not remove) thumb screw or knob as indicated in Figure 18 and adjust pan or tilt as desired.
Gallery Series LED Luminaire, please contact Altman Lighting technical support or your local Authorized Dealer. If you have any questions regarding the use or care of your Gallery Series LED Luminaires, please contact Altman Lighting technical support at support@altmanlighting.com or your local Authorized Dealer.
