- Page 1 Quick Start Guide Chalice 200 Pendant 1400 East 66th Avenue - Denver, CO 80229 USA +1 303 500-7072 - www.Altmanlighting.com...
- Page 2 Have a question regarding this manual? The material in this manual is for information purposes only and is subject to change without notice. Altman Lighting assumes no responsibility for any errors or omissions which may appear in this manual. For comments and sugges- tions regarding corrections and/or updates to this manual, please visit the Altman Lighting web site at www.altman-...
-
Page 3: Important Information
Chalice 200 Pendant Quick Start Guide Important Information Product Safety Notices When using electrical equipment, basic safety precautions should always be followed including the following: 1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 2. Do not mount near gas or electric heaters. -
Page 4: Fcc Notice
Altman Lighting, Inc., a subsidiary of Altman Stage Lighting Company, Inc., herein referred to as Altman, warrants each new product (except for spare parts or products Altman does not manufacture) for a period of TWO (2) years from date of shipment to correct by repair or replacement any part defect due to faulty material or workmanship. Under these same terms products with an LED light source shall be warranted for a period of FIVE (5) years and One (1) day. -
Page 5: Table Of Contents
Chalice 200 Pendant Quick Start Guide Table Of Contents Important Information Product Safety Notices Warnings FCC Notice Altman Lighting Product Warranty Warranty Terms Warranty Service Table Of Contents Product Overview Overview Models Accessories Installation & Set Up Mounting C-Clamp Installation... -
Page 6: Product Overview
Green, Blue, Lime LED engine offers very high output of deep rich saturated colors as well as soft and delicate pas- tels. The Chalice 200 also comes in a Tunable White, 3000K and 5000K LED Engine. The Chalice 200 Pendant repli- cates the soft output of a par wash light while maintaining a uniform beam output throughout the entire zoom range. -
Page 7: Installation & Set Up
Chalice 200 Pendant Quick Start Guide Installation & Set Up Mounting These instructions must be followed to provide a safe and secure mounting. Chalice must be installed by a qualified professional installer. Supporting mechanism and structure must be capable of supporting the weight of the Chalice 200. -
Page 8: Safety Cable Installation
1. Attach hook clamp or clamp of choice to the yoke. 2. Attach luminaire to structure. 3. Attach safety cable if required. 12" 9" 0° 16" Chalice 200 Pendant with Yoke Mount Chalice 200 Pendant with Yoke Mount Parts Breakout Page 8... -
Page 9: Pendant With Stem
Maintain a minimum distance of 2.94 inches from top of luminaire to stem end to avoid pinching power and data Chalice 200 Pendant Mount cables. Pendant Stem Spec Page 9... -
Page 10: Pendant With Aircraft Cable
Quick Start Guide Chalice 200 Pendant Pendant with Aircraft Cable Chalice pendant with aircraft mount, are intended for permanent installation are is designed to be suspended below a ceiling installed junction box or similar mount. Mounting hardware is NOT provided with Chalice. -
Page 11: Wall Mount
2. Attach luminaire to bracket using supplied hardware 3. Connect data and power wiring. Side View Wall Mount Top View Wall Mount Side View 178mm 7.01in .12in 9" 3" " 7" 178mm 7.00in 224mm 8.80in 7" Chalice 200 Pendant with Wall Mount Parts Breakout Page 11... -
Page 12: Power Requirements
Quick Start Guide Chalice 200 Pendant Power Requirements Chalice 200 must be connected and properly grounded to an viable earth ground. Chalice 200 must be connected to a constant circuit or a relay device. MUST NOT BE CONNECTED TO A DIMMER. -
Page 13: Connecting To The Dmx512 Network
USITT Contact Information: www.usitt.org At the end of each DMX Daisy chain, it is highly recommended that a DMX TERMINATOR (Altman Light- ing part number DMX-MPHX-TERM for the connectors shown in Table 2) is utilized on the last luminaire (or device) in the chain. -
Page 14: Operation And Programming
Quick Start Guide Chalice 200 Pendant Operation and Programming Setting a DMX Address via RDM Chalice 200 LED Luminaires are full featured Remote Device Management (RDM) compliant. All DMX and Luminaire settings are programmed via a RDM ANSI E1.20 complaint device. As many of the RDM devices and software work dif- ferently please consult the RDM programmer manufacturer for specific operational instructions. -
Page 15: Dmx Personalities Settings
Chalice 200 Pendant Quick Start Guide DMX Personalities Settings Chalice 200 fixtures have a number of different configurations as shown in the DMX Personalities Settings Table and in the following section as an example of channel order layout. Input Value... -
Page 16: Cleaning And Care
This section covers portions of the luminaire that can be removed for cleaning. The Chalice 200 Pendant requires special care when it comes to cleaning the front reflector assembly. Additional care needs to be taken with the plastic components because they are much easier to scratch or damage than glass. -
Page 17: Troubleshooting
The chart below provides possible causes and remedies for various error messages and/or symptoms. If this chart is unable to address your issue, please contact your authorized dealer or Altman customer service for assistance. Any service and maintenance (including troubleshooting), other than described herein should be performed by an Authorized Altman Lighting Dealer or Service Center. -
Page 18: Specifications
Quick Start Guide Chalice 200 Pendant Specifications Specifications LED Source Electrical LED Engine 12X20 Watt RGBL Voltage Range 100-240 VAC, 50/60 Hz Max Power Consumption 222 Watts Input Connection Neutrik Power Con / Terminal Block Connection Rated LED Life: Arrays are rated for >50,000 to Current Inrush At 120 VAC, 50A (1/2 cycle) @25°C... - Page 20 1400 East 66th Avenue - Denver, CO 80229 USA +1 303 500-7072 - www.Altmanlighting.com...
