DMX Map Guide
Chalice 200 Pendant
1400 East 66th Avenue - Denver, CO 80229 USA
+1 303 500-7072 - www.Altmanlighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chalice 200 Pendant and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Altman Chalice 200 Pendant

  • Page 1 DMX Map Guide Chalice 200 Pendant 1400 East 66th Avenue - Denver, CO 80229 USA +1 303 500-7072 - www.Altmanlighting.com...
  • Page 2 Have a question regarding this manual? The material in this manual is for information purposes only and is subject to change without notice. Altman Lighting assumes no responsibility for any errors or omissions which may appear in this manual. For comments and sugges- tions regarding corrections and/or updates to this manual, please visit the Altman Lighting web site at www.altman-...
  • Page 3: Important Information

    Chalice 200 Pendant DMX Map Guide Important Information Product Safety Notices When using electrical equipment, basic safety precautions should always be followed including the following: 1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 2. Do not mount near gas or electric heaters.
  • Page 4: Fcc Notice

    Altman Lighting, Inc., a subsidiary of Altman Stage Lighting Company, Inc., herein referred to as Altman, warrants each new product (except for spare parts or products Altman does not manufacture) for a period of TWO (2) years from date of shipment to correct by repair or replacement any part defect due to faulty material or workmanship. Under these same terms products with an LED light source shall be warranted for a period of FIVE (5) years and One (1) day.
  • Page 5: Table Of Contents

    Chalice 200 Pendant DMX Map Guide Table Of Contents Important Information Product Safety Notices Warnings FCC Notice Altman Lighting Product Warranty Warranty Terms Warranty Service Table Of Contents DMX Control Modes RGBL 16 Bit Direct Mode RGBL 8 Bit Direct Mode...
  • Page 6: Dmx Control Modes

    DMX Map Guide Chalice 200 Pendant DMX Control Modes This section covers the available DMX mapping options and their control. RGBL 16 Bit Direct Mode RGBL (Red, Green, Blue, Lime) 16 Bit Direct Mode allows for the direct control of both coarse and fine (high and low byte) of color and the master intensity channels, as well as zoom, preset, strobe, control, and fan channels.
  • Page 7: Cmy 16-Bit Mode

    Chalice 200 Pendant DMX Map Guide CMY 16-bit Mode CMY (Cyan, Magenta, Yellow) 16bit mode allows for control of the Red, Green, Blue and Lime LEDs with a layer of logic applied to mimic the behavior of a subtractive color mixing fixture. Instead of adding colors to mix a new color, the logic of CMY is to start with white and dial in colors by subtracting cyan, magenta, and yellow until the desired color is made.
  • Page 8: Hsic Mode

    DMX Map Guide Chalice 200 Pendant HSIC Mode HSIC (Hue, Saturation, Intensity, Color Point) mode allows for the high resolution control of hue with a single channel control of intensity, saturation, and CCT (Correlated color temperature). HSIC mode will produce color fades around a color space with a variable CCT channel in the center to adjust the color temperature of the luminaire.
  • Page 9: Compact Mode

    Chalice 200 Pendant DMX Map Guide Compact Mode Compact mode provides direct 8-bit control over the color channels and strobe with no other attributes. This mode is the smallest DMX footprint on Chalice 200. Zoom and other attributes can still be set manually.
  • Page 10: Preset / Color Filters Channel

    DMX Map Guide Chalice 200 Pendant Preset / Color Filters Channel CHANNEL DESCRIPTION FUNCTION Channel OFF (disabled) = DMX 0-4 Preset_1 = DMX 5-7 Preset_2 = DMX 8-10 Preset_3 = DMX 11-13 Preset_4 = DMX 14-16 Preset_5 = DMX 17-19...
  • Page 11: Strobe Channel

    Chalice 200 Pendant DMX Map Guide Strobe Channel CHANNEL DESCRIPTION FUNCTION Open = DMX 0 - 2 Closed = DMX 3 - 5 Slow Rand(0.4hz) = DMX 6 - 7 Med Rand(5hz) = DMX 8 - 10 Fast Rand(30hz) = DMX 11 - 12 Strobe Range(0.4-30hz)
  • Page 12: Recording Color Presets From A Console

    Note: The following settings can only be achieve when the fixture is either set to DMX Map 8bit or 16bit. Note: For a more accurate CCT output it is recommended to turn on Calibration. See Chalice 200 Pendant Quick Start Guide for more information.
