Altman SS-STRIP series Specifications

200/400/600 Watt LED
6' Spectra Strip Linear Wash
Features:
Color Mixing via Red, Green, Blue & Amber Luxeon
Rebel LED's
White Light via 3000°K high CRI Luxeon Rebel LED's
for no color & tinting applications, as well as for use
with standard color filters.
Dual-Slot accessory frame holders per compartment
for use with lenses, diffusing, and color media.
Convection cooled without the use of fans
Compatible with DMX and RDM protocols. DMX
Address assignable via RDM or on-board push
button display
User selectable 8 and 16-Bit personalities for smooth
fades from 0 to 100%
Flicker–free "on camera" operation
Preset Modes to emulate 3 and 4 Circuit traditional
strip lights, as well as cell by cell control.
ARCHITECTURAL/ THEATRICAL
Fixture Type:
The SPECTRA STRIP is a low profile 6' LED Linear
Wash Luminaire with (12) compartments of 50w RGBA
Color Mixing or 3000°K high CRI White Light LED
Engines. Each compartment can be individually filtered,
lensed, or diffused using the dual filter slots provided per
compartment.
White light compartments are suitable for no color wash
applications, as well as tinting the RGBA Light engines
in
compartments can be used with traditional color media.
Suitable for both Floor and Pipe mounted applications,
the low-profile SPECTRA STRIP is a capable LED
Replacement for traditional Theatrical Strip Lights, Foot
Lights, and Borderlights.
800.4.ALTMAN Fax:914.963.7304
a blended wash.
Preliminary Specifications
Specifications subject to change without notice.
Low Profile fixture suitable for uplighting and
footlight applications.
On board multi-voltage power supply
Available Black, White, and Silver paint finishes
Weight: Approximately 48 lbs. (21.78kg)
ETL & cETL pending for Indoor use
57 Alexander Street, Yonkers, NY 10701 Tel: 914.476.7987, 212.569.7777;
LIGHTING
Catalog Number
SS-STRIP-*-**-***
Additionally, White Light
