- Page 1 Controller Mini LCCONTROL/MINI WE ’ RE HERE TO HELP: 1 (844) LIGHTCLOUD 1 (844) 544-4825 support@lightcloud.com...
-
Page 2: Product Features
Hello The Lightcloud Controller Mini is a remotely controlled switch and 0-10V dimming device. Product Features Wireless Control & Configuration Switching up to 4.2A 0-10V Dimming Power Monitoring Patent Pending... -
Page 3: Specifications
Contents Lightcloud Controller Lock Nut O-ring Instruction Manual Wire Nuts Specifications PART NUMBER OPERATING TEMPERATURE LCCONTROL/MINI -35ºC to +60ºC INPUT OVERALL DIMENSIONS 120V-277VAC, 60Hz 1.6" diameter, 3.8" length <0.8W (Standby and Active) 1/2" NPT Mount, Male 18AWG pigtails MAXIMUM SWITCHED LOAD RATINGS... -
Page 4: What You Need
What You Need Lightcloud Gateway A Lightcloud installation requires at least one Lightcloud Gateway to manage your devices. WE ’ RE HERE TO HELP: 1 (844) LIGHTCLOUD or 1 (844) 544-4825 support@lightcloud.com... - Page 5 Wiring Load or Fixture Lightcloud ® Controller Mini 120-277 VAC...
-
Page 6: Setup And Installation
Find a Suitable Location Use these guidelines when installing devices: • If there is a clear line of sight between two Lightcloud devices, they can be placed up to 1000 feet apart. • If the two devices are separated by ordinary drywall construction, try to keep them within 100 ft. - Page 7 Setup & Installation (cont’d) Install your Lightcloud Controller Install at a Junction Box (Indoor/Outdoor) To Load BLACK WHITE Lightcloud ® Controller Mini BLACK MODULAR CABLE PURPLE PINK 0-10V DIMMING 0-10V is a common method of low-voltage control of dimmable drivers and ballasts. Purple: 0-10V positive | Pink: 0-10V common...
- Page 8 Install at Lighting Panel or Trough WHITE BLACK Space and code allowing, you may install Lightcloud devices directly in your breaker box or lighting panel. Alternatively, break out lighting circuits and install Lightcloud devices in a separate trough. Controller requires constant, unswitched power.
- Page 9 Labeling Your device When installing devices, it’s important to keep track of their Device IDs, installation locations, panel/circuit #s, dimming function, and any additional notes. To organize this information, use the Lightcloud Installer Application (A) or Device Table (B). Lightcloud Installer Application Install the LC Installer Application: LC Installer is available for iOS and Android.
- Page 10 Send to RAB: Once all of the devices have been added and organized, submit the information for commissioning. Power up To add new devices to your Lightcloud network, call RAB at 1 (844) LIGHTCLOUD, or email us at support@lightcloud.com.
- Page 11 3 Blinks - Best signal 2 Blinks - Acceptable signal 1 Blinks - Unacceptable signal Consult the “Finding a Location” section for more information Commission your devices Log on to www.lightcloud.com or call 1 (844) LIGHTCLOUD...
- Page 12 POWER LOSS DETECTION: If mains power to the Controller is lost, the device will detect this and alert the Lightcloud application. EMERGENCY DEFAULT: If communication is lost, the Controller may optionally fall back to a specific state, such as turning the attached circuit on.
- Page 13 FCC Information: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This device has been tested and found to comply with the limits for Class A digital devices pursuant to Part 15A Subpart B, of the FCC rules.
- Page 14 Lightcloud is a commercial wireless lighting control system. It’s powerful and flexible, yet easy to use and install. Learn more at lightcloud.com 1 (844) LIGHTCLOUD 1 (844) 544-4825 support@lightcloud.com © 2022 RAB Lighting, Inc...
