- Page 1 Welcome 347/480V Controller LCCONTROL/4 8 0 WE ’ RE HERE TO HELP: 1 (8 4 4 ) LIGHTCLOUD 1 (8 4 4 ) 54 4 -4 8 2 5 support@lightcloud.com...
-
Page 2: Product Features
Hello The Lightcloud Controller is a remotely controlled switch and 0-10V dimming device. Product Features Wireless Control & Configuration Switching up to 2 A 0-10V Dimming Power Monitoring Patent Pending... -
Page 3: Specifications
Contents Lightcloud Controller Lock Nut Gasket Instruction Manual Wire Nuts Specifications OPERATING TEMPERATURE PART NUMBER -40 ºC to +40 ºC LCCONTROL/480 INPUT OVERALL DIMENSIONS 347-480 VAC, 50 /60 Hz 1 .58" diameter, 5.90 " length <2W(Standby) – 4W(Active) 1 /2" NPT Mount, Male... -
Page 4: What You Need
What You Need Lightcloud Gateway A Lightcloud installation requires at least one Lightcloud Gateway to manage your devices. WE ’ RE HERE TO HELP: 1 (8 4 4 ) LIGHTCLOUD or 1 (8 4 4 ) 54 4 -4 8 2 5... - Page 5 Wiring Load or Fixture GREY GREY (0-10V DIMMING) (0-10V DIMMING) PURPLE PURPLE BLACK/ BLACK/ WHITE WHITE TRIGGER TRIGGER STRIPED STRIPED SENSE SENSE (BROWN) (BROWN) BLACK BLACK 34 7/4 8 0 VAC...
-
Page 6: Setup And Installation
Find a Suitable Location Use these guidelines when installing devices: • If there is a clear line of sight between two Lightcloud devices, they can be placed up to 1 0 0 0 feet apart. • If the two devices are separated by ordinary drywall construction, try to keep them within 1 0 0 ft. - Page 7 Setup & Installation (cont’d) Install your Lightcloud Controller Install at a Junction Box (Indoor/Outdoor) To Load TRIGGER SENSE (BROWN) NEUTRAL / PHASE B Lightcloud ™ Controller LINE / PHASE A PURPLE GREY GREY (0-10V DIMMING) (0-10V DIMMING) 0-10V DIMMING 0 -1 0 V is a common method of low-voltage control of dimmable drivers and ballasts.
- Page 8 PHASE B LINE / PHASE A Space and code allowing, you may install Lightcloud devices directly in your breaker box or lighting panel. Alternatively, break out lighting circuits and install Lightcloud devices in a separate trough. Controller requires constant, unswitched power.
- Page 9 Install the LC Installer Application: LC Installer is available for iOS and Android. Scan & Install Lightcloud Devices: Scan each device and assign to a room. It’s recommended that each device is scanned just before or just after being wired so no devices are missed.
- Page 10 Solid GREEN when connected to your Lightcloud network. Blinking RED when not connected. The device will automatically continue trying to connect to a network in Setup Mode. Commission your devices Log on to www.lightcloud.com or call 1 (8 4 4 ) LIGHTCLOUD...
- Page 11 Operating Modes CONTROLLER: Provides switching and dimming for a single zone. REPE ATER: Extends the Lightcloud mesh network without controlling a load. TRIGGER: Detect when an attached circuit is open or closed. For example, you could attach the Controller in Trigger mode to an existing occupancy sensor to allow your Lightcloud system to react to the sensor.
- Page 12 If mains power to the Controller is lost, P OWER LOSS DE TEC TION : the device will detect this and alert the Lightcloud application. If communication is lost, the Controller may E M E R G E N C Y D E F A U L T : optionally fall back to a specific state, such as turning the attached...
- Page 13 FCC Information: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This device has been tested and found to comply with the limits for Class A digital devices pursuant to Part 15A Subpart B, of the FCC rules.
- Page 14 It’s powerful and flexible, yet easy to use and install. Learn more at lightcloud.com 1 (8 4 4 ) LIGHTCLOUD 1 (8 4 4 ) 54 4 -4 8 2 5 support@lightcloud.com Custom manufactured in China...
