User Manual
V21.01
Model: DGODWMNT55
Description: 55" Outdoor Wall Mounted Non-Touch Digital Signage
Scan QR code to visit the product page:
Operating Instructions for Digital Signage
Note: Before using the product, please read the instructions carefully!
Do not attempt to disassemble this product. If the product does not work properly, please call
our Customer Service Department at 1-844-221-3393.
1 / 27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGODWMNT55 and is the answer not in the manual?

Questions and answers

Summary of Contents for Displays2go DGODWMNT55

  • Page 1 User Manual V21.01 Model: DGODWMNT55 Description: 55" Outdoor Wall Mounted Non-Touch Digital Signage Scan QR code to visit the product page: Operating Instructions for Digital Signage Note: Before using the product, please read the instructions carefully! Do not attempt to disassemble this product. If the product does not work properly, please call our Customer Service Department at 1-844-221-3393.
  • Page 2: Table Of Contents

    Contents Features...............................3 Safety Warnings and Precautions...................... 3 Assembly and Connection........................5 Packing List............................5 Interfaces............................6 Steps for Unpacking........................6 TO MOUNT WALL BRACKET......................7 Remote Control..........................11 Description of Basic Operation......................12 Power on/Standby.........................12 About Launch Desktop........................12 Description of Wallpaper Switch....................12 File Manager..........................12 Local Settings..........................13 Status of Menu bar........................14...
  • Page 3: Features

    Thank you for purchasing the high-performance multi-functional LED backlight Digital Signage from Displays2Go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory. However, improper installation and use may result in electric shock and fire.
  • Page 4 WARNING  Do not use power supply other than AC 110V, 60Hz.  Cut off the power supply before connecting or disconnecting any cables.  Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. ...
  • Page 5: Assembly And Connection

    NOTE: DRILL IS REQUIRED FOR ASSEMBLY. TWO PEOPLE REQUIRED TO LIFT AND HANG SIGNAGE. NOTE: Contact Displays2Go if you have questions about the operation, debugging and connection of the unit, if the unit doesn’t work normally, please cut off the power immediately and consult the dealer. The unit is class-A product, which may cause radio...
  • Page 6: Interfaces

    interference in living environment. In this case, please take feasible measures, and use power plug as the disconnection device. Interfaces 1. Power Socket 2. USB Port 3. USB Port 4.RJ45 Port(Ethernet) 5. HDMI Port NOTE: Please pull out the power plug before installing or disassembling the unit! Steps for Unpacking 1.
  • Page 7: To Mount Wall Bracket

    TO MOUNT WALL BRACKET 1. Remove the bracket and fix it on the wall: a. Remove the two screws, as shown in Figure 1. b. Remove the bracket, as shown in Figure 2. (Fig. 1) (Fig. 2) c. Pay attention to front and back sides while installing brackets: ...
  • Page 8 2. Landscape Installation: a. Two people are required to lift the device and hang it on the bracket. Move the machine carefully and make sure the device has been hung before letting go (Fig. 7). b. Re-lock the two screws just removed from the bracket in Step 1a. (Fig. 8) to prevent the machine from shaking.
  • Page 9 3. For vertical installation: a. Remove these two brackets with a 6mm hex wrench, as shown in Figure 12. (Fig. 11) (Fig. 12) b. Rotate these two brackets and re-lock it on the device, as shown in Figure 13. (Fig. 13) (Fig.
  • Page 10 d. Make sure the device has been hung on the bracket tightly and whether the two screws have been locked, as shown in Figure 17. e. After the device is installed, gently shake the device to confirm whether the machine has been fixed tightly (Fig.18).
  • Page 11: Remote Control

    Remote Control Installing batteries for the remote control: Remove the battery cover and insert two AAA batteries (1.5V). Ensure that the battery polarity matches the “+”/“-” marks in the battery compartment of the remote control. Precautions for using the remote control: ...
  • Page 12: Description Of Basic Operation

    Description of Basic Operation Power on/Standby Insert the power plug into the outlet. Then the Digital Signage will be turned on. In power on state, enter “System Assistant” and press the “ ” button on the remote control, and the Digital Signage enters standby state.
  • Page 13: Local Settings

    Fig. 3 Local Settings 1. Click the Main Apps button “ ” in the Home page to enter the “APPS” menu interface (Fig. 1) 2. Click the “Settings” icon in the “APPS” menu interface (Fig. 2) and enter “Wi-Fi” menu (Fig. 3), 3.
  • Page 14: Status Of Menu Bar

    Description of Settings Interface (shown on the right) Icon Function WIFI switch Bluetooth Data usage Display Notifications Sound Apps Screenshot Setting Storage Battery Memory Users Location Security Accounts Google Languages & input Backup & reset Date & time Status of Menu Bar Click "...
  • Page 15: Diviex App Introduction

    DiViEx APP Introduction System requirements: Step 1: Before using this application, make sure your machine meets or exceeds the following system requirements: RK3288 16GB Operating system Android 7.1 How to upload media files : Step 2: Make new directory named “MediaFolder” in root directory in U disk. Open "MediaFolder", create 3 subfolders, and change their names to "Images", "Videos", "Music".
  • Page 16: Setting

    Step 4:When the screen shows “Copy finished” after “Usb Disk:”, Setting: Step 1: Select the time you would like each picture to be on the screen for by dragging the bar to the desired time. Select how you would like the images to display. Select the desired transition effect between pictures. Auto Boot ...
  • Page 17: Edit Picture

    Edit picture: This function show all pictures, you can edit all pictures, and remove it. Edit picture  There are four corners and four border to crop the picture, you can drag it Filter  Set different filter for the picture, we support the following filter: AUTO_FIX, BLACK_WHITE, BRIGHTNESS, CONTRAST, CROSS_PROCESS, DOCUMENTARY, DUE_TONE, FILL_LIGHT, FISH_EYE, FLIP_HORIZONTAL, FILP_VERTICAL, GRAIN, GRAY_SCALE, LOMISH, NEGATIVE, PSTERIZE, ROTATE, SATURATE, SEPIA, SHARPEN, TEMPERATURE, TINT, VIGNETTE.
  • Page 18: Music

    Music: List all music files int Playlist library Add music to playing list music from Playlist library, you can click right arrow, music title will show the  number of playlist music. To remove background music from the playlist, click the left arrow in the playlist ...
  • Page 19: Screen Rotate

    Fig. 3 Screen Rotate: 1. Click the Main Apps button “ ” in the Home page to enter the “APPS” menu interface (Fig. 1) 2. Click “System aide” into Fig. 2 3. Choose the degree you would like to Rotate screen, then click “Confirm”, after the restart, the screen will be rotated (Fig.
  • Page 20: Choose System Language

    Choose System Language: 1. Get into Settings, then click “Language & input” (Fig. 1) 2. Click “Languages”, then click “Add a language” (Fig. 3) 3. You can add the required system language (Fig. 4) 4. Drag the system language you just added up to the front(Fig. 5) Fig.
  • Page 21: Technical Specifications

    Technical Specifications ITEM SPECIFICATION LCD size 55” Light source LED backlight Resolution 1920*1080 (pixels) Brightness (typ.)/(min) 2000cd/m (typ.) Contrast (typ.) 1200:1 (typ.) Response (ms) 10ms (typ.) Panel Pixel pitch 0.21(H) mm * 0.63 (V) mm Refresh rate 60Hz Viewing angle 178°...
  • Page 22 Supported Video Files AVI, MPEG4, WMV, MKV Supported Photo Files JPG, JPEG, BMP, PNG, GIF Audio output, supported files Left and right audio channel, MP3 Functions RTC (real-time clock) Schedule power on/off System update USB compatible App installation Support download and installation Ethernet (RJ45) HDMI I/O interfaces...
  • Page 23: Troubleshooting

    Troubleshooting the Digital Signs – DGODWMNT55 Issue Probable Cause Solutions No picture or sound Unit not plugged into wall outlet   □ Check that the unit is plugged into wall Power cord not properly  outlet. connected to the terminal on the □...
  • Page 24 Did you purchase the   □ If you purchased DisplayIt!Xpress software with installing DisplayIt!Xpress software from from Displays2go or from Best Wave directly, software or getting Displays2go? please contact Best Wave at content to play Did the customer purchase or ...
  • Page 25: Cleaning And Maintenance

     Android board is defective. Images> Editor > Paste Open SlideShow app and select desired trasitions, slide time and looping > Play MX Player steps > Follow same steps as SlideShow App > MediaFolder > Video > Editor > Paste. Open MX Player and select video to play.
  • Page 26: Names And Contents Of Toxic And Hazardous Substances Or Elements In The Product

    Names and Contents of Toxic and Hazardous Substances or Elements in the Product Toxic and hazardous substances or elements Part name PBDE Display О О О О О Shell О О О О × × Circuit board assembly * О О...
  • Page 27 FCC STATEMENT: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
