Operating Basics

Usage

80E07, 80E08, 80E09, and 80E10 User Manual
This chapter makes you familiar with the operation of your sampling module. It
describes the controls and connectors, interaction of the sampling module with
your instrument, programming the sampling module, and user adjustments.
Figure 5 shows the sampling module and remote modules and identifies the
buttons, lights, and connectors.
CAUTION. To prevent damage to your sampling module or instrument, do not
apply a voltage greater than the Maximum Input Voltage (see page 49) for your
sampling module.
To prevent electrostatic damage to the instrument and sampling modules, follow
the precautions described in this manual and the manuals accompanying your
instrument. (See Electrostatic Discharge starting on page 8.)
Always use a wrist strap (provided with your instrument) when handling
sampling modules or making signal connections.
The input circuitry in your sampling module is very susceptible to damage from
overdrive signals and electrostatic discharge. Never apply a DC or peak voltage
greater than the Maximum Input Voltage (see page 49) of your sampling module.
Only operate the instrument and sampling module in a static-controlled
environment.
11
