Argos 875/7276 Assembly Instructions Manual

Download this manual

ARGOS Ltd.

KD Sea Grass Chest

Easy Assembly Instructions

Introduction

Tools required:

Allen Key –

Supplied.

Issue date: 27/03/2007

Revision number: 3

Care & Use.

• Dust with a clean cloth / duster.

• Do not use water.

• Do not allow to become damp.

Note: Do not tighten any of the screws until all parts are together.

875/7276 (D)

Need help?

Do you have a question about the 875/7276 and is the answer not in the manual?

Page 1 ARGOS Ltd. KD Sea Grass Chest 875/7276 (D) Easy Assembly Instructions Care & Use. Introduction • Dust with a clean cloth / duster. Tools required: • Do not use water. • Do not allow to become damp. Allen Key –...
Page 2 Components / fixings list Components Fixings Screws x 16 Hinge rods x 4 Allen key - supplied Hooks x 2 A – Rear Panel B – Front Panel C – Base board D – Lid E – Left hand side F –...
Page 3 ASSEMBLY – STAGE ONE Front / Base / Sides assembly. 1. Attach part ‘A’ Back Panel to part ‘C’ Base using 3 screws. The screws should only be screwed in 2 or 3 turns until ALL panels are in place. Then fully tighten all the screws.
Page 4 ASSEMBLY – STAGE TWO Front / Lid assembly 3. Attach part ‘B’ Front panel to Sides & Base, using 7 screws. Finally fully tighten all screws. 4. Attach Lid ‘D’ to chest assembly, by locating the hinge flaps together & then securing by pushing the ‘Rods’...
Page 5 ASSEMBLY – STAGE THREE Final lid assembly 5. Attach the chain on the lid & on the rear inside face of each side to the hook as shown. Issue date: 27/03/2007 Revision number: 3...
