Technical
Manual
Table of Contents
Specification..................................... 1
Parts List.......................................... 2~4
Wiring Diagram ...............................
PCB Assembly................................. 6
Schematic Diagram..........................7
Specifications
Power Configuration
Watts/Channel all channels driven, with 20kHz
8 ohm load, 20Hz to 20kHz, <0.02% THD
4 ohm load, 1kHz, <1% THD
Peak Output Current
Total Harmonic Distortion
At rated power,20Hz-20kHz
At one-half rated power, 20Hz-20kHz
At 1 watt per channel, 20Hz-20kHz
Intermodulation Distortion at rated power,60Hz:7 kHz, 4:1
Damping Factor 8 ohms
Amplifier Gain
Input Sensitivity/Impedance
Frequency Response ±3dB
Signal to Noise Ratio IHF A network
Power Requirements
Power Consumption
Idling Power Consumption
Standby Power Consumption
Dimensions (W x H x D)
Front Panel Height (for rack mount)
Weight (net)
10-10 SHINSEN-CHO , SHIBUYA-KU,
TOKYO 150-0045, JAPAN
FIVE CHANNEL POWER AMPLIFIER
RMB-1085
5
5 x 100 watts
100 watts
180 watts
11 amps
< 0.02%
< 0.03%
< 0.03%
< 0.03%
200
27.2dB
1.25V/8.2 kohms
10Hz–40kHz
105dB
110-240 volts
250 watts
30 watts
6 watts
432 x 72 x 382 mm
17
/
x 9
1
8
60mm
5.4 kg, 11.9 lb.
/
x 15
/
in
3
1
8
8
Serial. NO.
-2
7501001~
Y-408B-0804/pdf
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Rotel RMB-1085-2
Summary of Contents for Rotel RMB-1085-2
- Page 1 Technical FIVE CHANNEL POWER AMPLIFIER Manual RMB-1085 Table of Contents Specification........1 Parts List.......... 2~4 Wiring Diagram ....... PCB Assembly......... 6 Schematic Diagram......7 Specifications Power Configuration 5 x 100 watts Watts/Channel all channels driven, with 20kHz 8 ohm load, 20Hz to 20kHz, <0.02% THD 100 watts 4 ohm load, 1kHz, <1% THD 180 watts...
- Page 2 Appearance RMB-1085/ -2 FIVE CHANNEL POWER AMPLIFIER RMB-1085 POWER PROTECTION Please request: When the fault are in the 200ASC or 200AC module, replace the module and send back the modules later.
- Page 3 Parts List 1/1 RMB-1085-2 SYMBOL PARTS NO. DESCRIPTION 016 X-1511B01-03 PCB ASSY 501 X-1511 PCB ASSY (MAIN BOARD) H1,H2 017 4TR-2792#1 SUB HEAT SINKER L=25 (D907,908) 019 0009-P POWER TR BUSH (D907,908) 019 TO-220 MICA SHEET TBM-51W-15 #9036 L901 021 2698200001...
- Page 4 Addendum List for Black and Silver RMB-1085/ -2 SYMBOL PARTS DESCRIPTION 011 FP-632-B BLACK PANEL ASSY 011 FP-632-S SILVER PANEL ASSY 011 VA3-01A00 H/S PANEL H60 012 RV4-09A00 PUSH BUTTON 14F (BLK) 012 RV4-09A01 PUSH BUTTON 14F (SLV) 034 SEL1124R LED (RED) 1X5 034 SEL1E24W LED (BLU) 1X5...
- Page 5 RMB-1085/ -2 WIRING 501 X-1511-02 K12B K14B K10B ICEPOWER ICEPOWER ICEPOWER ICEPOWER ICEPOWER WIRING CNT ASSY PCB.etc X-1511-02 X-1511-01 200ASC(S-R) 200A(F-R) 200A(C) 200A(F-L) 200ASC(S-L) 068 C-4586A05 D901 POWER LED (2P 420MM) 501 X-1511-01 K 2 2 B K 2 9 B K 3 1 B 068 C-4586A06 K 2 6 B...
- Page 6 PCB Assembly RMB-1085-2 MAIN PCB 016 X-1511B01~03...
- Page 7 Schematic Diagram RMB-1085-2...
