3. Block Diagram

+Vin
-Vin
CNT
SG

4. Sequence Time Chart

Vin
Input Voltage
0V
Vout
Output Voltage
0V
H
*1
ON/OFF Control
L
H
IOG
L
H
*2
AUX
L
*1 Level : 4≦H≦35(V) or Open
0≦L≦0.8(V) or Short
