Care and cleaning of the range.
Burner heads
Slot
Electrode
The burner heads are removable.
Simply lift them off the range for
cleaning.
Hole in
burner
head
The oval burner head/cap assembly is
removable. Simply lift it off the range
for cleaning. Use a sewing needle or
twist-tie to unclog the small hole in
the burner heads.
32

Burner Caps and Heads

Before removing the burner caps and heads,
remember their size and location. Replace them in
the same location after cleaning.
NOTE: Do not use steel wool or scouring powders to
clean the burner parts.
Burner caps
Lift off when cool. Wash burner caps in hot,
soapy water and rinse with clean water. You
may scour with a plastic scouring pad to
remove burned-on food particles.
Burner Heads and Oval (Center) Burner
Head/Cap Assembly
The burner heads and the oval burner head/cap
assembly are removable. Simply lift them off the
range for cleaning.
For proper ignition, make sure the
small hole in the section that fits over the
electrode is kept open. A sewing needle
or wire twist-tie works well to unclog it.
The slits in the burner heads must be kept clean
at all times for an even, unhampered flame.
Clogged or dirty burner ports or
electrodes will not allow the burner to
operate properly.
Any spill on or around an electrode must
be carefully cleaned. Take care to not hit an
electrode with anything hard or it could be
damaged.
Clean the burner heads routinely, especially
after bad spillovers, which could clog the
openings. Lift off when cool.
To remove burned-on food, soak the
burner heads in a solution of mild liquid
detergent and hot water for 20–30 minutes.
For more stubborn stains, use a toothbrush.
After cleaning
Before putting the burner caps, heads and
oval head/cap assembly back, shake out
excess water and then dry them thoroughly
by setting in a warm oven for 30 minutes.
Replacement
Burner Heads
Replace burner heads over the electrodes
on the cooktop, in the correct locations
according to their size. There is one small,
one medium, one large and one extra large
burner head.
Medium head
Large head
Front of range
Make sure the slot in the burner head is
positioned over the electrode.
Electrode
Slot
Oval (Center) Burner Head/Cap Assembly
Replace the oval (center) head/cap
assembly over the electrode on the cooktop.
Oval head and cap
Make sure the slot in the
assembly
burner head is positioned
over the electrode.
Front of range
Caps
Replace the matching size caps onto the
burner bases or heads.
Medium cap
Large cap
Front of range
Make sure that the heads and caps are
replaced in the correct locations.
Small head
Extra large head
Slot
Electrode
Small cap
Extra large cap
