1
Before moving the range indoors:
• Remove outer carton and packing material
S tep
Remove
Packaging
• Remove the kick panel by removing 2 screws
The range is secured to the skid with 2 bolts in
the front and 2 "L" brackets on the bottom
flange of the range back. Remove bolts and
"L" brackets.
To simplify handling and to reduce the weight
of the range:
• Remove the grates and drawers below the
• Remove grill and griddle covers. DO NOT
• Remove the broiler pans/literature package
8
from the shipping base.
Kick Panel
at the top and pulling forward.
knobs.
ATTEMPT TO REMOVE A GRILL OR
GRIDDLE ASSEMBLY.
from inside oven(s).

Installation

Remove oven doors:
• Open the door fully and hold down.
• Close the brass hinge latches to locked
position on each side.
• Carefully, lift and pull the door away from the
range and out of the frame.
Left Rear Shipping
Screws
Due to the weight of these ranges, use a dolly
with soft wheels to move this range.
• Lift the range onto the dolly and move
indoors.
Professional Ranges
Door Hinge Roller
Leveling Legs
Lock
(Closed)
Un-Lock
Range Must
be Uniformly
Supported
on Braces
22"
