Advance Planning; Tools & Materials Required - GE Monogram ZDP30L4HSS Installation Instructions Manual

Refer to "Dimensions and Clearances" for
Advance
appropriate placement and necessary clear-
Planning
ances when planning the installation.
• Cabinetry can not be installed directly above
• We recommend the installation of a vent
• Working areas adjacent to the range should
• Clearance between range and side wall or
If the range is installed in an island:
• Allow 12" min. clearance at the back to
• Saw
Tools &
• Measuring tape
Materials
• Carpenter's square
• Pipe and fittings as required.
Required:
• Manual gas line shut-off valve.
• Gas pressure regulator (supplied)
• Large flat-blade screwdriver
• Pipe wrench
• Drill and appropriate bits
• Safety glasses
6
the range.
hood above the surface.
–The vent hood must be at least 24" deep.
–The vent hood must be the same width as
the range.
–For 48" models, we recommend the vent
hood blower be 1200 CFM.
–For 30" and 36" models, we recommend the
vent hood blower be 600 CFM.
have 18" minimum clearance between
countertop and cabinet bottom.
combustible material must be at least 12" on
each side.
combustible materials.
Design Information
Professional Ranges
• Allow 36" min. above the cooking surface to
combustible materials.
• For 48" models, we recommend the vent
hood blower be 1200 CFM.
• For 30" and 36" models, we recommend the
vent hood be 600 CFM.
• Installation must conform with local codes.
In the absence of local codes, the range
must comply with the National Fuel Gas
Code, ANSI Z223.1, latest edition.
A.G.A. approved.
• Gas-resistant pipe joint sealant
• 5 foot, 5/8" AGA-certified flexible metal gas
supply line.
–If required by local codes, use solid pipe
fittings.
Note: Purchase new flexible line. DO NOT
USE OLD, PREVIOUSLY USED FLEXIBLE
LINE.
