HBC(X), PHBC(X), RHBC(X), CHBC(X)
HORIZONTAL HYDRONIC FAN COIL UNITS
Installation, Operation, and
Maintenance Instructions
W
ARNING TO
Altering the product, improper installation, or replacing parts with unauthorized parts voids
all warranty or implied warranty and may result in adverse operational performance or
possible hazardous conditions to service personnel and occupants. Company employees or
contractors are not authorized to waive this warning. Current Maintenance Program is
available
HERE.
NOTES:
•
• These instructions are intended as a general guide and do not supersede
• These instructions must be left with the property owner.
S
C
AFETY
ONSIDERATIONS
Improper installation, adjustment, alteration, service, maintenance, or use can
cause explosion, fire, electrical shock, or other conditions which may cause
personal injury or property damage. Consult a qualified licensed installer,
service agency, or your distributor for information or assistance. The qualified
licensed installer or service agency must use factory-authorized kits or
accessories when modifying this product. Refer to the individual instructions
packaged with kits or accessories when installing.
Follow all safety codes. Wear safety glasses and work gloves. Use quenching
cloth for brazing operations. Have fire extinguisher available. Read these
instructions thoroughly and follow all warnings or cautions attached to the
unit. Consult local building codes and National Electrical Code (NEC) for special
requirements.
IOM4501 Rev. A 06/18
I
, S
NSTALLER
Read the entire installation instruction manual before starting the
installation.
national, state, or local codes in any way.
P
,
ERVICE
ERSONNEL
AND
O
WNER
1
Advertisement
Table of Contents
Related Manuals for First Co HBC
Summary of Contents for First Co HBC
- Page 1 HBC(X), PHBC(X), RHBC(X), CHBC(X) HORIZONTAL HYDRONIC FAN COIL UNITS Installation, Operation, and Maintenance Instructions ARNING TO NSTALLER ERVICE ERSONNEL WNER Altering the product, improper installation, or replacing parts with unauthorized parts voids all warranty or implied warranty and may result in adverse operational performance or possible hazardous conditions to service personnel and occupants.
- Page 2 National Electric Code, ANSI/NFPA No. 70 (latest edition) in the United States, as well as any state laws and local codes. Local authorities having jurisdiction should be consulted before installation is made. Such HBC(X), PHBC(X), RHBC(X), CHBC(X) Installation, Operation, and Maintenance Instructions...
-
Page 3: Installation Precautions
Use the directional arrows or other information on the filter to determine • the proper flow direction. • Ensure air distribution system does not exceed the external static rating of the unit. HBC(X), PHBC(X), RHBC(X), CHBC(X): Installation, Operation, and Maintenance Instructions... - Page 4 If mounting to wooden joists, use as a minimum 1/4” x 2” wood screws fully engaged with fender washers for securing this unit to the structure. HBC(X), PHBC(X), RHBC(X), CHBC(X) Installation, Operation, and Maintenance Instructions...
- Page 5 These units are provided with a Class 2 transformer for 24-volt control circuits. Should any add-on equipment also have a Class 2 transformer furnished, care must be taken to prevent interconnecting outputs of the two transformers by using a thermostat with isolating contacts. HBC(X), PHBC(X), RHBC(X), CHBC(X): Installation, Operation, and Maintenance Instructions...
-
Page 6: Piping Installation
• When connecting piping to fan coil units, do not bend or reposition the coil header tubing for alignment purposes. This could cause a tubing fracture resulting in a water leak when pressure is applied to the system. HBC(X), PHBC(X), RHBC(X), CHBC(X) Installation, Operation, and Maintenance Instructions... -
Page 7: Piping Insulation
CHBC(X) fan coil units require a minimum trap of 1-1/2 inches provided in the drain line to assure proper drainage. HBC(X) and PHBC(X) fan coil units may be located where the return air space is large enough that a negative pressure is not present, however, a trapped condensate line is recommended in case a negative condition should occur, the unit would drain properly. - Page 8 PIPING Determination of Right-Hand/Left-Hand References FIGURE 1. Coil Assemblies (Right-Hand Shown) FIGURE 2. 3 Row 3/2 Row HBC(X), PHBC(X), RHBC(X), CHBC(X) Installation, Operation, and Maintenance Instructions...
- Page 9 All valves will operate at any angle with the exception of the motorized valve, which must never be installed with the power head below horizontal. The actuator box requires a 3/4-inch clearance for removal. Three-Way Motorized Valve Assembly FIGURE 4. HBC(X), PHBC(X), RHBC(X), CHBC(X): Installation, Operation, and Maintenance Instructions...
-
Page 10: Pre-Startup Checks
Ensure condensate line is properly sized, run, trapped, pitched and tested. Ensure all cabinet openings and wiring connections have been sealed. Ensure a clean filter is in place and of adequate size. Ensure all access panels are in place and secured. HBC(X), PHBC(X), RHBC(X), CHBC(X) Installation, Operation, and Maintenance Instructions... -
Page 11: Maintenance
MAINTENANCE maintained. A current copy of the Maintenance Program log can be found at MAINTENANCE www.firstco.com under “Product Information,” or click HERE. UPDATES HBC(X), PHBC(X), RHBC(X), CHBC(X): Installation, Operation, and Maintenance Instructions...
