CHASSIS / BODY
Rear Side Support
Screws
Chaincase Housing
Cooler / Bulkhead
Fasteners
Front Bumper Fasteners
Clutch Cover Flange Nut
Upper Over-Structure
Fasteners
Lower Over-Structure
Flanged Nut
Running Board Bracket
Fasteners
Front Lower Over-
Structure Screws
Rear Lower Over-
Structure Screws
Upper Snow Flap
Fasteners
Front Side Support
Screws
Rear Closeoff Acorn Nut
ELECTRICAL
ELECTRICAL
ITEM
Battery Bracket Nuts
Battery Bracket Fastener
Battery Terminal
Hardware
Battery Box Bracket
Fasteners
Starter Motor Mounting
Fasteners
Starter Motor Positive
Cable Nut
Starter Motor Pinion
Fasteners
Starter Motor Clip Bracket
Fasteners
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
26 ft-lbs (35 Nm)
Replace with new when
removed.
26 ft-lbs (35 Nm)
Replace with new when
removed.
7 ft-lbs (10 Nm)
7.5 ft-lbs (10 Nm)
12.5 ft-lbs (17 Nm)
22 ft-lbs (30 Nm)
9 ft-lbs (12 Nm)
22 ft-lbs (30 Nm)
9 ft-lbs (12 Nm)
Hand Tight
26 ft-lbs (35 Nm)
16 in-lbs (1.8 Nm)
TORQUE
7 ft-lbs (10 Nm)
22 ft-lbs (30 Nm)
36 in-lbs (4 Nm)
22 in-lbs (2.5 Nm)
7 ft-lbs (10 Nm)
8 ft-lbs (11 Nm)
7 ft-lbs (10 Nm)
8 ft-lbs (11 Nm)
GENERAL INFORMATION
ELECTRICAL
ITEM
PBR Mounting Fasteners
PIDD Bracket Fasteners
1
TORQUE
6 ft-lbs (8 Nm)
6 ft-lbs (8 Nm)
1.67
