Polaris 850 PRO-RMK 155 2020 Manual page 72

GENERAL INFORMATION
AXYS FRONT SUSPENSION
Handlebar Hook Screw
Handlebar Mount Bolts
PERC Button Screw
Hand Guard Mounts
Auxiliary Engine Stop
Switch Set Screw (All)
Handlebar Hook Screw
Throttle Lever Block Set
Screw
Throttle Lever Block
Cover Screw
REAR SUSPENSION
AXYS REAR SUSPENSION
Front torque Arm Tunnel
Mount Fasteners
FTS Shock Fastener
Limiter Strap Fasteners
Upper Carrier Fasteners
RTS Shock Fastener
Rear Crank to Rear Pivot
Fasteners
Rail Slider Fastener
Extrusion Bumper
Fastener
Scratcher Fastener
Rail Cap Fastener
Rear Idler Fastener
Front Brace Fastener
Rear Rail Brace Fastener
Rear Torque Arm Brace
Shaft Fastener
Rear Torque Arm
Fastener
1.66
Aluminum: 10 ft-lbs
(13.5 Nm)
Steel: 18 ft-lbs (24 Nm)
7 ft-lbs (9.5 Nm)
35 in-lbs (4 Nm)
Hand-Tight
12 in-lbs (1.4 Nm)
Aluminum: 10 ft-lbs
(13.5 Nm)
Steel: 18 ft-lbs (24 Nm)
27 in-lbs (3.1 Nm)
6 in-lbs (0.7 Nm)
46 ft-lbs (63 Nm)
17 ft-lbs (23 Nm)
17 ft-lbs (23 Nm)
46 ft-lbs (63 Nm)
33 ft-lbs (45 Nm)
17 ft-lbs (23 Nm)
3-6 ft-lbs (4-8 Nm)
Torque until fastener
protrudes 5 +/- 0.75 mm
out of nut
14 ft-lbs (19 Nm) +/- 20%
4 ft-lbs (5.5 Nm) +/- 20%
55 ft-lbs (75 Nm) +/- 10%
33 ft-lbs (45 Nm)
33 ft-lbs (45 Nm) +/- 10%
55 ft-lbs (75 Nm) +/- 10%
6 ft-lbs (8 Nm)
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
AXYS REAR SUSPENSION
Front Boogie Wheel
Fastener
Rear Torque Arm to Rear
Pivot Fasteners
Front Torque Arm Tunnel
Mounts
FTS Rail Brace Fasteners
Front Pivot Fasteners
Bumper Fastener
Rail Tip Fastener
Rail Slider Fastener
Shock Rod Fasteners
Walker Evans Clicker
Assembly Nut
Walker Evans Shock
Body Cap / Tube
Walker Evans Shock Rod
Lock Nut
Walker Evans Shock Rod
Bearing Cap
Walker Evans Shaft
Eyelet
Walker Evans Seal Head
Assembly
CHASSIS
CHASSIS / BODY
Fender Screws
Rear Bumper Bolts
Chaincase Rear Mounting
Nuts
Lower Tunnel Cooler
Screws
Chassis Flanged Nut
Cast Clip Side Screws
50 ft-lbs (68 Nm)
17 ft-lbs (23 Nm)
47 ft-lbs (64 Nm)
50 ft-lbs (68 Nm)
33 ft-lbs (45 Nm)
Torque until screw
protrudes 5mm out of
nut
4 ft-lbs (6 Nm)
4 ft-lbs (6 Nm)
33 ft-lbs (45 Nm)
10 ft-lbs (14 Nm)
30 ft-lbs (41 Nm)
20 ft-lbs (27 Nm)
10 ft-lbs (14 Nm)
30 ft-lbs (40 Nm)
10 ft-lbs (14 Nm)
36 in-lbs (4 Nm)
17 ft-lbs (23 Nm) Apply
Loctite 263
9 ft-lbs (12 Nm)
26 ft-lbs (35 Nm)
Replace with new when
removed.
26 ft-lbs (35 Nm)
Replace with new when
removed.
9 ft-lbs (12 Nm)
