FINAL DRIVE / BRAKES
ITEM
Brake Reservoir Cover
Fasteners
Brake Fluid Reservoir
Mounting Fasteners
Brake Lever Hinge Pin
Master Cylinder
Handlebar Clamp
Fasteners
Brake Banjo Bolt
Brake Bleeder Screw
PVT SYSTEM
PVT SYSTEM
ITEM
Drive Clutch Bolt
Drive Clutch Cover
Fasteners
Drive Clutch Spider
Drive Clutch Spider Jam
Nut
Clutch Weight Pin
Starter Ring Gear
Fasteners
Driven Clutch Bolt
Driven Clutch Helix
Fasteners
Team Deflection Jam Nut
FRONT SUSPENSION
AXYS FRONT SUSPENSION
Upper Shock Mounting
Fastener
Ski Assembly Fastener
Control Arm Fastener
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
TORQUE
11 - 13 in-lbs (1.2 - 1.4
Nm)
10 - 13 in-lbs (1.13 - 1.47
Nm)
96 - 120 in-lbs (10.85 -
13.56 Nm)
60 - 80 in-lbs (6.8 - 9 Nm)
240 - 264 in-lbs (27 - 30
Nm)
100 - 135 in-lbs (11 - 15
Nm)
TORQUE
80 ft-lbs (109 Nm)
Re-torque after running
engine
100 in-lbs (11 Nm)
Use cross pattern
280-300 ft-lbs (380-406
Nm)
290-330 ft-lbs (394-447
Nm)
25 in-lbs (3 Nm)
165 in-lbs (19 Nm)
18 ft-lbs (25 Nm)
110 in-lbs (12 Nm)
145 in-lbs (16 Nm)
DO NOT OVER-TORQUE
36 ft-lbs (50 Nm)
36 ft-lbs (50 Nm)
40 ft-lbs (54 Nm)
GENERAL INFORMATION
AXYS FRONT SUSPENSION
Lower Shock Mounting 18 ft-lbs (25 Nm)
Fastener
Control Arm Fastening 40 ft-lbs (54 Nm)
Nut
Upper Shock Fastening 36 ft-lbs (50 Nm)
Nut
Handlebar Hook Fastener 10 ft-lbs (13.5 Nm)
Handlebar Mount 7 ft-lbs (9.5 Nm) -
Fastener Tighten Gap Evenly
Steering Post Bushing 18 ft-lbs (25 Nm)
Fasteners
Lower Steering Post 22 ft-lbs (30 Nm)
Bushing Fasteners
Draglink Assembly 37 ft-lbs (50 Nm)
Fasteners
Rack Link Assembly 20 ft-lbs (27 Nm)
Fasteners
Steering Assembly Idler 30 ft-lbs (41 Nm)
Fasteners
Steering Post Fasteners 22 ft-lbs (30 Nm)
Tie Rod Fastening Nut 37 ft-lbs (50 Nm)
Sway Bar Bushing Clamp 30 ft-lbs (41 Nm)
Fastener
Sway Bar Link Fastener 18 ft-lbs (25 Nm)
Throttle Cover Screws 6 in-lbs (0.7 Nm)
Auxiliary Stop Switch 12 in-lbs (1.4 Nm)
Mount Screw
Throttle Block Set Screw 27 in-lbs (3.1 Nm)
Tie Rod Jam Nut 11 ft-lbs (15 Nm)
Ski Bolt Nuts 37 ft-lbs (50 Nm)
Ski Skag Fasteners 7 ft-lbs (10 Nm)
Rear Ski Loop Fasteners 6 ft-lbs (8 Nm)
Front Ski Loop Fasteners 9 ft-lbs (12 Nm)
Upper Control Arm Rod 44 ft-lbs (60 Nm)
End Fastener
Master Cylinder 60 - 80 in-lbs (6.8 - 9 Nm)
Handlebar Clamp Screws
Auxiliary Engine Stop 12 in-lbs (1.4 Nm)
Switch Set Screw
