GENERAL INFORMATION
ENGINE
ITEM
Exhaust Valve Base
Fasteners
(M6 x 1.0 x 50)
EV Actuator Mounting
Fasteners
(M6 x 1.0 x 15)
EV Actuator Push / Pull
Cable Jam Nut
Engine Mounting
Fasteners
(M10 x 1.5 x 40)
Excluding Front MAG
Engine Mount
Front MAG Engine
Mounting Fasteners
(M8 x 1.25 x 25)
Exhaust Manifold
Fasteners
Fuel Rail Fasteners
(M7 x 1.0 x 63)
Reed / Throttle Body
Adapter Fasteners
FUEL SYSTEM
FUEL SYSTEM
ITEM
Exhaust Gas
Temperature (EGT)
Sensor
Engine Coolant
Temperature (ECT)
Sensor
Knock Sensor Fastener
ECU Mounting Fasteners
Front Seat Mount
Fastener
1.64
TORQUE
9 ft-lbs (12 N·m)
9 ft-lbs (12 N·m)
13 ft-lbs (18 N·m)
48 ft-lbs (65 N·m)
Apply Loctite 262
22 ft-lbs (30 N·m)
First Pass: 11 ft-lbs
(15 N·m)
Second Pass: 22 ft-
lbs (30 N·m)
First Pass: 5 ft-lbs
(6.5 N·m)
Second Pass: 15 ft-
lbs (20 N·m)
Always discard fasteners
and replace with new.
12 ft-lbs (16 N·m)
TORQUE
32 ft-lbs (44 Nm)
18 ft-lbs (24 Nm)
168 in-lbs (19 Nm)
5 ft-lbs (7 Nm)
36 in-lbs (4 Nm)
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
FUEL SYSTEM
ITEM
Fuel Tank Rear Mounting
Fastener
Rear Seat Mount Bracket
Nuts
Fuel Tank Bracket
Shoulder Fastener
Fuel Tank Front Mounting
Fastener
PFA Nut
Throttle Position Sensor
Fasteners
FINAL DRIVE / BRAKES
FINAL DRIVE / BRAKES
ITEM
Chaincase Cover
Fasteners
Drive Chain Tensioner
Jam Nut
Chaincase Fill Plug
Chaincase Rear Mounting
Nuts
Chaincase Housing
Cooler / Bulkhead
Fasteners
Chaincase Lower
Sprocket Fastener
Brake Disc Fastener
Speed Sensor Fastener
QuickDrive Upper/Lower
Sprocket Fasteners
QuickDrive Backer Nuts
QuickDrive Backer
Screws
Driveshaft Bearing Cover
/ Flangette Fasteners
Jackshaft Bearing Flange
Fasteners
Torque Link Stud Nut
TORQUE
10 ft-lbs (14 Nm)
10 ft-lbs (14 Nm)
5 ft-lbs (7 Nm)
10 ft-lbs (14 Nm)
28 ft-lbs (38 Nm)
31 in-lbs (3.5 Nm)
TORQUE
11 ft-lbs (15 Nm)
21 ft-lbs (28 Nm)
4 ft-lbs (6 Nm)
9 ft-lbs (12 Nm)
26 ft-lbs (35 Nm)
29 ft-lbs (40 Nm)
40 ft-lbs (54 Nm)
7ft-lbs (10 Nm)
44 ft-lbs (60 Nm)
9 ft-lbs (12 Nm)
26 ft-lbs (35 Nm)
18 ft-lbs (25 Nm)
22 ft-lbs (30 Nm)
22 ft-lbs (30 Nm)
