- Page 1 ARQIS Series CABINET LOUDSPEAKERS Architectural Loudspeaker Cabinets USER MANUAL...
-
Page 2: Table Of Contents
INDEX IMPORTANT REMARK ..................3 IMPORTANT SAFETY INSTRUCTIONS .............. 4 IMPORTANT NOTE ..................6 INTRODUCTION ..................... 6 MODELS ......................6 5.1. ARQIS105 ....................... 6 5.2. ARQIS106 ....................... 7 5.3. ARQIS108 ....................... 7 5.4. ARQIS205 ....................... 7 5.5. ARQIS208 ....................... 8 5.6. -
Page 3: Important Remark
1. IMPORTANT REMARK The lightning flash with arrowhead symbol, within an equilateral “dangerous voltage” within the product’s enclosure that may be of triangle, is intended to alert the user to the presence of uninsulated sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 4: Important Safety Instructions
2. IMPORTANT SAFETY INSTRUCTIONS Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. manufacturer’s instructions. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the 8. - Page 5 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 6: Important Note
3. IMPORTANT NOTE Congratulations! You are the owner of carefully designed and manufactured equipment. We thank you for trusting in us and choosing our ARQIS Series loudspeaker cabinets. In order to get the optimum operation and efficiency from this unit, it is VERY IMPORTANT - before you plug anything - to read this manual very carefully and bear in mind all considerations specified within it. -
Page 7: Arqis106
5.2. ARQIS106 • 120 WRMS @ 8 Ω • Full range, 2-way architectural loudspeaker • 6,5" woofer • 1" compression driver (rotable) • Double INPUT/STACK connector, Euroblock type, with security attachment screws to avoid accidental disconnection • Wall bracket included, allowing for pan & tilt adjustment, employing a single screw for fastening •... -
Page 8: Arqis208
5.5. ARQIS208 • 300 WRMS @ 8 Ω • Full range, 2-way architectural loudspeaker • 2 x 8" woofer • 1" compression driver (rotable) • Double INPUT/STACK connector, Euroblock + Speakon© type, with security attachment screws to avoid accidental disconnection •... -
Page 9: Arqissb6T
5.8. ARQISSB6T • 6,5" subwoofer + 6,5" pasive radiator • Ready for 70/100V installations: power selector 60/120W & 8 ohm • Euroblock connector and spring loaded input terminals • LPF cut-off frequency selection: OFF/ 120Hz / 150Hz • Wall-mount hardware included •... -
Page 10: Connections
6. CONNECTIONS The connection cables which connect the amplifiers output and the speaker should be of good quality, have sufficient conductor area and be as short as possible. The latter fact is especially important when the distance is long and the load impedance low (4-8 W). -
Page 11: Installation
9. INSTALLATION In the ARQIS series, the best way to install the enclosure was studied for each model. Each model from the ARQIS range is supplied with the optimal installation system. ARQIS205 / ARQIS208 / ARQIS110 / ARQIS 112 / ARQISSB10 / ARQISSB15 also have built-in M8 rigging points for suspension from a compatible structure or "truss"... -
Page 12: Technical Specifications
10. TECHNICAL SPECIFICATIONS ARQIS105 ARQIS106 ARQIS108 Ways 8Ω 8Ω Impedance 8 RMS power 70 WRMS 120 WRMS 175 WRMS Program power 140 WRMS 240 WRMS 350 WRMS SPL 1W/1m 89 dB 92dB 93dB Max SPL @ 1m 110 dB 116dB 118dB Frequency response (±3dB) 85Hz÷20kHz... - Page 13 ARQIS110 ARQIS112 Ways 8Ω 8Ω Impedance RMS power 220 WRMS 340 WRMS Program power 440 WRMS 680 WRMS SPL 1W/1m 95dB 97dB Max SPL @ 1m 118dB 122dB Frequency response (±3dB) 60Hz÷18kHz 60Hz÷18kHz Cross-over frequency 3.5kHz 2.5kHz 90⁰x50⁰ 80⁰x40⁰ Dispersion (HxV) 10”...
-
Page 14: Installation Diagrams
11. INSTALLATION DIAGRAMS Wall bracket assembly diagram... - Page 15 HOLES FOR SRDA DISPERSION OPTIONAL ACCESSORY ARQIS106 ARQIS108 60º ARQIS205 ARQIS208 90º ARQIS series installation diagram...
- Page 16 All product characteristics are subject to variation due to production tolerances. NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing Motors, 166‐168 08038 Barcelona ‐ Spain ‐ (+34) 932238403 that may affect these product specifications. information@ecler.es www.ecler.com...
