3.3 iT500RX receiver switch functions
Receiver possible LED colours:
1
2
4
5
1. AUTO - receiver operate in automatic mode
(works according to thermostat or app)
2. MANUAL - receiver operate according to the switch located below
3. OFF - receiver is disabled
4. CH - in manual mode, zone 1 is turned ON
5. AUX - in manual mode, zone 2 (or DHW) is turned ON
6. CH/AUX - in manual mode, zone 1 and zone 2
(or DHW) are turned ON
3
6
17
