- Page 1 Energy Saving Thermostat [Insert product picture] Instruction Manual Model no. GES2181 1 ...
- Page 2 CONTENTS 2 ...
-
Page 3: Product Overview
PRODUCT OVERVIEW The GES2181 Energy Saving Thermostat can connect to 3 Heat / 2 Cool conventional Heat Pump HVAC systems. The thermostat’s smart ZigBee™ technology enables it to communicate with your utility company so you can receive messages about energy saving events and price reductions. In addition, the easy‐to‐use interface makes it simple to control your energy consumption. SAFETY INSTRUCTIONS Purpose and correct use: • Read these instructions carefully and keep in a safe place for future reference. • Only an authorized, qualified installer should install this unit. All manual / safety instructions and electricity supplier’s regulations must be adhered to. • Only connect this unit to a 24‐volt A/C power source. • Do not install this unit at an altitude of over 2000 meters. • This standalone mounted electronic unit serves as a temperature control system only in dry, closed living and office spaces. Do not place the unit in a bathroom or area of excessive moisture. Do not allow the unit to get wet. • Place the unit in an easy‐to‐reach position where you can comfortably reach the buttons and view the screen. • Do not expose the unit to: temperatures below 5°C or above 40°C; humidity above 80% or pollution above level 2. • Do not expose the unit to voltage fluctuations of more than +/‐ 10%. • Clean the unit with a dry, soft cloth. Do not use solvents or aggressive cleaning agents. The manufacturer accepts no responsibility for damage caused by non‐observance of these instructions. Environmental Protection Unwanted electrical appliances can be recycled and should not be discarded along with regular household waste. Please help to support the conservation of resources and protect the environment by returning this appliance to your nearest collection centre (if available). INSTALLATION ... -
Page 4: Set Heat/Cool Mode
The large temperature reading on the Home screen is the current temperature. The small temperature reading is your setpoint temperature. To quickly change the setpoint temperature: Press UP or DOWN. When you receive an event or message from the utility company, ‘Event’ or ‘Message’ appears on the bottom of the Home screen and advises how many events or messages you have received, and the event’s level of importance. SET HEAT/COOL MODE 1. When you are in the Home screen, press SYS and the screen opposite appears. 2. Press SYS repeatedly to select one of the following options: • ‘Heat’, ‘Cool’ or ‘Off’ (Conventional HAVC) • ‘Heat’, ‘Emer’ (Emergency Heating), ‘Cool’ or ‘Off’ (Heat pump HVAC) 3. Press MENU to confirm your selection and return to the Home screen. Note: Make sure you press MENU to confirm your changes or they will not be saved. SET FAN MODE 1. When you are in the Home screen, press FAN and the screen opposite appears. 2. Press FAN repeatedly to select ‘Fan On’ or ‘Fan Auto’. 3. Press MENU to confirm your selection and return to the Home screen. Notes: • When the fan is set to ‘Auto’ it only runs when th e heating/cooling system is working. • Make sure you press MENU to confirm yo ur changes or they will not be saved. ... -
Page 5: Override Menu
2. Press UP or DOWN to scroll through the Main menu op tions. 3. Press SELECT to enter a menu. Note: Make sure you press MENU to confirm your change s or they will not be saved. Override menu When you receive an event or message from the ut ility company, ‘Event’ or ‘Message’ appears on the bottom of the Home screen and advises how m any events or messages you have received, and the event's level of importance. You can view the details by repeatedly pressing INFO (see the ‘Viewing events and me ssages’ section for more information). In the Override menu, you can choose to accept or reject events and messages, and set the thermostat to ‘Vacation’ to override the programmed settings. o reject events: 1. Select and enter the Override menu. 2. Press UP or DOWN to select ‘Reject Current Event’ or ‘Rejec t All Events’. 3. Press SELECT to confirm. If you reject an event, a message appears to ask if you are sure you wan t to reject it, press SELECT to confirm the rejection or MENU to return to the previous scre en. Note: Once you have rejected a current event, the unit will cont inue to reject all new events. If you ... -
Page 6: Program Menu
When the vacation mode is activated, your utility company can override your temperature setting when the new event setting saves energy, for example: a) In wintertime when the outdoor temperature is cold, you may set your vacation temperature to 10°C to prevent pipes from freezing. However, if the utility company sends an event to reduce the temperature to 8°C to save energy, it will override your vacation temperature and make the new ‘Heat Set Point’ 8°C. b) In summertime, if you have set your vacation temperature to 20°C and the utility sends an event to increase the temperature to 25°C in order to save energy, it will override your vacation temperature and make the new ‘Cool Set Point’ 25°C. Note: The utility company cannot override your vacation temperature if you have set the unit to ‘Reject All Events’. Program menu To edit the time and temperature settings for any day of the week: 1. Select and enter the Program menu and the screen opposite appears. 2. Use UP or DOWN to scroll through the settings and press SYS or FAN to change a setting. 3. Press MENU to confirm and return to the previous screen. To copy or reset a program: 1. Select and enter the Program menu. 2. Press INFO and the screen opposite appears. 3. Use UP or DOWN to select ‘Copy Program’ or ‘Reset program’ and press SELECT to confirm. • If you selected ‘Copy Program’, use the UP and DOWN buttons to select a day that you want the program settings to be copied to and press SYS until the ‘N’ cha nges to a ‘Y’. Then ... -
Page 7: Setup Menu
Setup menu To edit the Setup menu: 1. Select and enter the Setup menu and the screen opposite appears. 2. Use UP or DOWN to scroll through the settings and press SYS or FAN to change a setting. 3. Press MENU to confirm. Here’s a list of what the Setup menu settings mean: Unit Changes the display measurement from Celsius to Fahrenheit or vice‐versa. If you select this option , ‘This action will restore all user [thermometric] settings to the default settings. Continue?’ displays. Press SELECT to confirm or MENU to exit and ret urn to the previous screen. Span Changes the temperature span from 0.5 to 2.0°F in increments of 0.5°. Fan The fan will continue to run for 0, 30, 60 or 90 seconds after cooling is turned off. Filter Sets a time (up to 500 hours) for the system to remind you to change or clear the fan’s filter. Default If you select this option, ‘Are you sure to RESTORE all settings to factory default’ displays. Press SELECT to confirm or MENU to exit and return to the previous screen. Time Changes the time. Date Changes the date. Get Network If you select and confirm ‘Yes’, a signal will be sen t out to search for the network time and this Time will be updated on your thermo stat. ... - Page 8 To disconnect from your utility network: 1. Select and enter the Ne tworking menu. You should see the ‘Joined’ screen opposite. 2. Press SELECT to disconnect and the message ‘Are you sure?’ appears. 3. Press and hold MENU and INFO simultaneously to co nfirm, or press MENU to exit and return to the pre vious screen. Note: The right LED lights up when you are disconnect ed. ry me nu The query men u allows you to retrieve and view recent events, prices or messages from your utili ty company. 1. S elect an d enter the Query menu and the screen opposite appears. 2. Use UP o r DOWN to scroll through the onscreen ries a nd press SELECT to enter the menu option: • ‘Get event’ – Press UP or DOWN to select the ...
- Page 9 WING EVENTS AND MESSA GES 1. When you are in the Home screen, press INFO repeatedly to view the following notifications from your utility company: Screen Description An Event EVENT: • Pending – An event will happen at the START TIME. • Active – This event is currently in progress. • Rejected – You have rejected this event. EL: There are 9 different event levels: • Green – Energy saving • Levels 1 ‐5 – Level of message importance; 1 is low and 5 is high • Emergen cy • Planned outage • Service Disco nnect START TIME: The event will start at this time i.e. 8am. DURATION: The event will last for this duration i.e. 2 hours. A Price Your current energy usage is priced at Level 1, which is currently $2.2 per kilowatt‐hour. ...
-
Page 10: Specifications
support yo u may be asked to provide these codes. When viewing any of these screens, lo ok in the top right‐hand corner to see how many pages there are i.e. 1/2. Use the UP and DOWN buttons to scroll through to the end of the message. INDICATORS There are two LEDs. One is Yellow in co lor and the other is tri‐color. The Yellow LED is for For HVAC system indication and Tri‐color (Green, Orange and Red) for Utility Information indication . Yellow Color LED: HVAC system working normal: Off HVAC system working normal with Network Identify Re quest from Server or utility company: Flashing HVAC system error/warnin g: On Tri‐color (red, green and) LED: Demand Response from Utility Compa ny is running: Red LED on Current energy price is at Low level: G reen LED on Curren t energy price is at Medium: Gr en LED on ... -
Page 11: Fcc Declaration
RF frequency 2.40 – 2.48 GHz RF range Up to 1300 Ft (400m) Line of Sight A/C power 18‐30 V AC at R and C terminals 13.6 (L) x 10.6 (W) x 2.6 (H) cm Size 5.4” (L) x 4.2” (W) x 1” (H) Weight 0.76lb (345g) FCC DECLARATION Warning: Changes or modifications to this unit not expressly approved by the party r esponsible for compliance could void the user’s authority to operate the quipm ent. This device complies wit h Part 15 of the FCC Rules. - Page 12 Rated Impu lse voltage: 330V For inst allation, please refer to the install ation and wiring diagram under Appendix Warning: Do not connect any of the termi nals to 110V/220V AC sup ply. 12 ...
- Page 13 Appendix: Installation and Wiring Diagram Terminal definition Heat Pump Terminal Conventional Heat Cool System System L No use System monitor 24VAC common for control circuit and thermostat C power input G Fan st Y stage cooling stage compressor stage cooling stage Y2 compressor W stage heating Auxiliary heating W2/E stage heating Emergency heating rd W3/O/B stage heating Changeover valve RH 24VAC Power supply for Heating side RC 24VAC Power supply for Cooling side 13 ...
- Page 14 iring diagram for Heat pump system Aux heating Emergency 14 ...
- Page 15 Wiring diagram for conventional Heat Cool system © 2010 Computime Limited 15 ...
