Montage
AT10: For installation, press the thermostat firmly to the heat pipe and
fix it with the supplied elastic band so that the thermostat is in direct
contact with the pipe (remove any insulation at the installation spot
before fixing the sensor). Excess elastic band can be trimmed.
AT10F: Fix the thermostat to a flat surface using screws. Then place the
measuring element (capillary) in the measuring sleeve, e.g. located in
the hot water tank.
Changing temperature setpoint
To set the temperature, pull the knob towards you to release it. Then
turn the knob to the position which indicates the required temperature.
To keep this setting, press the knob lightly in the inward direction until
a click is heard.
Technical informations
Power supply
Max. load
Output signal
Temperature adjustment range
Dimension [mm]
230V AC
16 (4) A
terminals 1/C/2 (NO/COM/NC)
30 – 90 °C
105 x 50 x 45
AT10F: length of the capillary:
1200, Ø of the capillary: 7
Contact thermostat / Capillary thermostat
Model: AT10, AT10F
User manual
