1. Package Contents Thank you for purchasing PLANET L2+ 8-Port 10/100/1000T 802.3at PoE + 2-Port 10/100/1000T + 2-Port 100/1000X SFP Managed Switch, GS-5220-8P2T2S. “L2+ Managed PoE+ Switch” mentioned in this quick installation guide refers to the GS-5220-8P2T2S. Open the box of the L2+ Managed PoE+ Switch and carefully unpack it. The...
2. Requirements z Workstations running Windows XP/2003/2008/2012/Vista/7/8/10, MAC OS X or later, Linux, UNIX, or other platforms are compatible with TCP/IP protocols. z Workstations are installed with Ethernet NIC (Network Interface Card). z Serial Port Connection (Terminal) The above Workstations come with COM Port (DB9) or USB-to-RS232 converter. The above Workstations have been installed with terminal emulator, such as Tera Term, PuTTY or Hyper Terminal included in Windows XP/2003.
3. Terminal Setup To configure the system, connect a serial cable to a COM port on a PC or notebook computer and to DB9 type of serial port of the L2+ Managed PoE+ Switch. PC / Workstation with Terminal Emulation Software Managed Switch RS232 to RJ45 Cable Serial Port RJ45 Console Port Figure 3-1: L2+ Managed PoE+ Switch Console Connectivity A terminal program, such as Tera Term or PuTTY, is required to make the software connection to the L2+ Managed PoE+ Switch.
3.1 Logging on to Console Once the terminal is connected to the device, power on the L2+ Managed PoE+ Switch and the terminal will display “running testing procedures”. Then, the following message asks to log in user name and password. The factory default user name and password are shown as follows and the login screen in Figure 3-3 appears.
3.2 Configuring IP Address The L2+ Managed PoE+ Switch is shipped with default IP address shown below. IP Address: 192.168.0.100 Subnet Mask: 255.255.255.0 To check the current IP address or modify a new IP address for the L2+ Managed PoE+ Switch, please use the procedures as follows: Show the current IP Address 1. At the “#” prompt, enter “show ip interface brief”. 2. The screen displays the current IP address as shown in Figure 3-4. Figure 3-4: IP Information Screen...
Page 8
Configuring IP Address 3. At the “#” prompt, enter the following command and press <Enter> as shown in Figure 3-5. GS-5220-8P2T2S # configure terminal GS-5220-8P2T2S (config)# interface vlan 1 GS-5220-8P2T2S (config-if-vlan)# ip address 192.168.1.100 255.255.255.0 Figure 3-5: Configuring IP Address Screen The previous command would apply the following settings for the L2+ Managed PoE+ Switch.
3.3 Storing Current Switch Configuration In the L2+ Managed PoE+ Switch, the running configuration sequence running- config can be saved from the RAM to FLASH by “copy” command, so that the running configuration sequence becomes the start-up configuration file, which is called configuration save. At the “#” prompt, enter the following command and press <Enter>. # copy running-config startup-config Figure 3-6: Saving Current Configuration Command Screen If you are not familiar with the console command or the related...
4. Starting Web Management The following shows how to start up the Web Management of the L2+ Managed PoE+ Switch. Note the L2+ Managed PoE+ Switch is configured through an Ethernet connection. Please make sure the manager PC must be set to the same IP subnet address.
4.1 Logging on to the L2+ Managed PoE+ Switch 1. Use Internet Explorer 8.0 or above Web browser and enter IP address https://192.168.0.100 (the factory default IP address or the one that you have just changed in console) to access the Web interface. 2. When the following dialog box appears, please enter the default user name and password “admin” (or the password you have changed via console). The login screen in Figure 4-2 appears.
Page 12
The Switch Menu on the top of the Web page lets you access all the commands and statistics the L2+ Managed PoE+ Switch provides. The Switch Menu always contains one or more buttons, such as “Refresh”, “Save”, “Help” and “Logout”. Figure 4-4: Switch Menu Figure 4-5: Switch Sub-menu If you are not familiar with Switch functions or the related param- eter, press “Help icon”...
4.2 Saving Configuration To save all applied changes and set the current configuration as a startup configuration on the Web user interface, the startup-configuration file will be loaded automatically across a system reboot. 1. Click the Save icon on the top Switch Menu bar. 2. Press the “Save Configuration” button. 3.
5 seconds. After the device is rebooted, you can log in the management Web interface within the same subnet of 192.168.0.xxx. 1000 + 2-Port 10/100/1000T + 8-Port 10/100/1000T 802.3at PoE 10/100 LNK 2-Port 100/1000X SFP Managed Switch 10 12 Console PoE-in-Use Reset GS-5220-8P2T2S 115200,N,8,1 Reset Button Figure 5-1: GS-5220-8P2T2S Reset Button...
