4.4

LS1 CARD

4.4.1

PRESENTATION AND CONFIGURATION

The LS1 card is used to connect:
•
two T0 accesses, or
•
one T0 access and one S0 interface, or
•
two S0 interfaces.
The LS1 card layout is detailed in the Configuration Data Report.
Description of connectors:
J1 - 96-pin connector to the back pane.
J2 - 2-pin stocko connector for connecting the 40 V power supply to S0 interfaces.
J3 - 4-pin stocko connector for connecting T0 or S0 interface to equipment 0.
J4 - 4-pin stocko connector for connecting T0 or S0 interface to equipment 1.
Description of switches:
SW1 equipment 0
1 2 3 4 5 6 7 8
ON
ON
OFF
Description of straps:
PAGE 60/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
f i r m w a r e P R O M
The black square corresponds to the switch position

Figure 16: Presentation of the LS1 card

9 10
OFF ON ON
OFF ON ON
ON OFF OFF
Equipment 0 Interfaces
ST1 ST2
1-2 1-2
T0
1-2 1-2
T0
2-3 2-3
S0
Interfaces SW2 equipment 1
1 2 3 4 5 6 7 8
T0 T0 ON
T0 S0 OFF
S0 S0 OFF
Equipment 1
ST3 ST4
1-2
T0
2-3
S0
2-3
S0
LCAH-30521-001-05=01/EN
9
OFF ON
ON ON OFF
ON OFF OFF
1-2
2-3
2-3
10
ON
