2.2.3

F2, F3, AND F4 SYSTEM RANGES

S0 interface cards
40 V remote power
supply
S0 interface cards
40 V or 48 V
remote power
supply
(configuration by
jumper)
1) LAS card: you must declare an external access on ADP or ADQ for the 40 V remote
power supply.
2) Where the number of radio base stations in a system slightly exceeds the maximum
number specified, the one or two excess radio base stations may be powered locally
using an additional PN840B power pack.
3) To operate 4-channel radio base stations, the LDSA or LDSB cards must be fitted with
ADPCM daughter cards.
4) 4-channel radio base stations are connected to LDS cards. To operate 4-channel base
stations, ADPCM daughter cards must be installed on the LDS cards (8 daughter cards
maximum per LDS card).
LDS cards without an ADPCM card operate on two channels.
Maximum capacity in release 11.4 (7599):
♦
MC 6504/40, 64 radio base stations on 4 LDSA cards
♦
MC 6550, 64 radio base stations for each CUG, with 4 LDSA cards for each UCG
(cluster control unit)
LCAH-30521-001-05=01/EN
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONSet ne doit pas être reproduit ou communiqué sans autorisation.
F2, F3, F4 systems
LAS card (reference HJ2467LD or later)
Eight 2-channel base stations (1)
Power supplies ADS850A and ADS850C
Sixteen base stations maximum per shelf (2)
Power supply ADS850IT
Thirty-two base stations maximum per shelf
LDSA card
Sixteen 2- or 4-channel base stations
ADS850IT power supply
sixteen base stations maximum per shelf
LDSB card
Eight 2- or 4-channel base stations
ADS850IT power supply
sixteen base stations maximum per shelf (3)
