2.2.2

F1 SYSTEM RANGE

S0 interface cards
40 V remote power supply
S0 interface cards
40 V or 48 V remote power
supply (configured by
(*) 4-channel radio base stations are connected to LD4 cards. To operate 4-channel base
stations, ADPCM daughter cards must be installed on the LD4 cards (2 daughter cards
maximum per LD4 card).
LD4 cards without an ADPCM card operate on two channels.
For MC 6501 PBXs release 11.3 (only with 2-channel base stations)
The MC 6501 PBX must be fitted with an OCT2 CPU card (HJ3547A) and MOCT2-C
daughter card (HJ4071A).
a) 40 V remote power supply:
♦
power supply, reference HR2940H or earlier
♦
maximum number of radio base stations: 8
b) 48 V remote power supply:
♦
LS1 card, reference HJ3924AC or earlier
♦
ADS200 power supply is mandatory
♦
maximum number of radio base stations: 16
LCAH-30521-001-05=01/EN
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONSet ne doit pas être reproduit ou communiqué sans autorisation.
One 2-channel base station maximum
LD4 card without ADPCM daughter card
Four 2-channel base stations maximum
jumper)
LD4 card with ADPCM daughter card (*)
Four 4-channel base stations maximum
MC 6501 systems
LS1 card (HJ2608EJ)
LS1 card (HJ3924AC or later)
Sixteen 2-channel base stations
maximum
