- Page 1 User’s Guide PIPETMAN® M Connected Software...
-
Page 2: Table Of Contents
Table of ConTenTs INTRODUCTION PIPeTMan® M Connected software overview | 2 set Password (optional) | 2 Institution/Company Profile (optional) | 2 Home screen | 3 CONNECT PIPETTE Connect via bluetooth | 4 CREATE AND MANAGE PROTOCOLS Create a Protocol | 6 Manage Protocols | 14 TRANSFER PROTOCOLS TO PIPETTE | 15 UPDATE PIPETTE SETTINGS... -
Page 3: Introduction
PIPeTMan M Connected software is an easy-to-use software for creating custom pipetting protocols for PIPeTMan M Connected. Use it to create personalized pipetting protocols on your PC or tablet and then transfer the protocols to PIPeTMan M Connected in the Custom Mode, where you can execute them. Software Compatibility ●... -
Page 4: Home Screen
Home Screen after starting PIPeTMan M Connected software, the Home screen appears. Figure 1 PIPeTMan® M Connected software Home screen (Tablet - Top, PC - bottom) InTRoDUCTIon | PIPeTMan® M ConneCTeD sofTWaRe... -
Page 5: Connect Pipette
► Manage protocols Create, edit, import, or export custom protocols. ► Transfer custom protocols to pipette Connect a PIPeTMan M Connected pipette via Usb cable (PC only) or bluetooth and then transfer a selected custom protocol to PIPeTMan M Connected. -
Page 6: Create And Manage Protocols
CReaTe anD Manage pRoToCols select Manage protocols to create, edit, import, or export protocols. PIPeTMan M Connected software stores information about custom pipetting protocols in specific files with the extension .pmp. CReaTe anD Manage PRoToCols | PIPeTMan® M ConneCTeD sofTWaRe... -
Page 7: Create A Protocol
2. on the protocol info tab, select the pipette from a list of PIPeTMan M Connected models. 3. enter the name of the user creating the protocol (protocol created by field). - Page 8 aVaIlable TasKs Aspirate aspirates specified volume into the tip. Beep Makes pipette produce a beeping sound while selected tasks are executed. Dispense Dispenses specified volume from the tip. Dispense all Dispenses all remaining volume from the tip followed by a purge action. Loop enables repetition of any task once or more.
- Page 9 Repetitive Distributes the same volume repeatedly in a pre-defined number of equal aliquots. Reverse Reverse pipetting where during aspiration, additional liquid is added and after delivery, the excess volume remains in the tip and is discarded. Wait adds a wait for a specified number of seconds. Wait for Click Pauses the protocol until the push-button is clicked.
- Page 10 ● Display text : enter text to display on the pipette’s lCD screen when the task is active. NOTE The number of characters for display text is limited. ● execute automatically: specify whether the task should be executed automatically after the previous task is completed. Beep The beep task has the following parameters: ●...
- Page 11 Loop The loop task has the following parameters: ● Task name: specify the name of the task. ● number of iterations: specify how many times the pipette should repeat the tasks that are placed inside the loop task. ● Comments: enter any comments related to the task The Mix task has the following parameters: ●...
- Page 12 Repetitive The Repetitive task has the following parameters: ● Task name: specify the name of the task. ● Comments: enter any comments related to the task. ● aliquot volume (µl): enter the requested volume for each aliquot. ● number of aliquots: enter the desired number of aliquots. The software automatically calculates the number of aliquots NOTE possible and will only allow you to enter a valid value.
- Page 13 Wait The Wait task has the following parameters: ● Task name: specify the name of the task. ● Duration (s): specify the duration of the pause in seconds. ● Comments: enter any comments related to the task. ● Display text: enter text to display on the pipette’s lCD screen when the task is active.
- Page 14 Warning and Error Messages PIPeTMan M Connected software verifies the protocol after the addition of each task or after modification of a task to determine whether the volume of the pipette is still within the volume specifications for that particular PIPeTMan M Connected model.
-
Page 15: Manage Protocols
► Edit edit a protocol (change the PIPeTMan M Connected model, rename protocol, add/edit/remove tasks. ► View View a protocol. no parameters can be changed in the “View mode”. -
Page 16: Transfer Protocols To Pipette
To import a protocol: select Import a protocol. 2. browse for and then select a pIpeTMan M Connected ble protocol file (.pmp). 3. If prompted, enter a new protocol name. 4. select Import. The protocol is now accessible in the Manage protocols screen. -
Page 17: Update Pipette Settings
6. select Chapter 6 UpDaTe pIpeTTe seTTIngs optionally, set the following options on PIPeTMan M Connected: ● set the beep to on or off (switches the tone of the pipette to on or off). beep on and off only affects the built-in pipette protocols, as well as aspirate, Dispense, Mix, Purge tasks (but noT beep task). -
Page 18: Update Pipette Firmware
► pipette management Manage the inventory of your PIPeTMan M Connected pipettes. ► View history View the history of protocol uploads to PIPeTMan M Connected pipettes and the history of protocol modifications by user. ► Change password Change the password to access PIPeTMan M Connected software. -
Page 19: Pipette Management
Pipette Management Register the Pipette When it is necessary to have the pipette connected, the software will prompt you. If the pipette has been registered previously, it is only necessary to activate the bluetooth on the pipette to make the connection;... -
Page 20: View History
View the history of protocol uploads to PIPeTMan M Connected pipettes (protocol upload tab) and the history of protocol modifications (protocol management tab). To display the history of protocol uploads to PIPeTMan M Connected pipettes, navigate to the protocol upload tab, select the time interval, and then select show history. - Page 21 noTes PIPeTMan® M ConneCTeD sofTWaRe | UseR’s gUIDe...
- Page 22 LT801600/B | ©2021 Gilson, Inc. All rights reserved.
