- Page 1 Heat Line Instructi ons for installati on and use English More documents on: www.zodiac-poolcare.com H0360800.D - 2016/02...
- Page 2 WARNINGS • Failure to respect the warnings may cause serious damage to the pool equipment or cause serious injury, even death. • The appliance is intended for a specifi c pool use and must not be used for any use other than that for which it was designed.
-
Page 3: Table Of Contents
It is prohibited to distribute or modify this document in any way without authorisati on from • Zodiac®. Zodiac® is constantly developing its products to improve their quality; therefore, the • informati on contained in this document may be modifi ed without noti ce. -
Page 4: ❶ Specifi Cati Ons
❶ Specifi cati ons 1.1 I Descripti on Heat Line + Heat Line without circulati ng pump (SC) Bare Heat Line N 1.2 I Technical specifi cati ons Heat Line Unit Primary °C Secondary °C Power Primary Flow rate m³/h Secondary Primary 0.015... -
Page 5: I Dimensions And Marking
1.3 I Dimensions and marking Front Heat Line 20-40 535 mm 665 mm 198 mm 328 mm Heat Line Multi -tube exchanger body ½ union PVC connector Ø63 to be glued Primary circuit drainage cap Glove fi nger Regulati on sensor Circulati ng pump Exchanger body att achment Electrical unit... -
Page 6: ❷ Installati On
❷ Installati on 2.1 I Selecti ng the locati on • The appliance must be installed in a technical room venti lated, dry and without stored pool treatment products. • Install the appliance as close as possible to the heati ng source (boiler, heat pump, geothermal, solar-powered heati ng, etc.), •... -
Page 7: I Hydraulic Connecti Ons
2.2 I Hydraulic connecti ons • Respect the hydraulic connecti on directi on (see the indicati ons on the exchanger tank). • Correctly ti ghten the hydraulic connecti ons and check for leaks. • Check that the pipe system is cleaned before connecti ng anything. : pool water inlet valve (secondary circuit) : pool water by-pass valve (secondary circuit) : pool water outlet valve (secondary circuit) -
Page 8: I Electricity Supply Connecti Ons (Depending On The Models)
2.3 I Electricity supply connecti ons (depending on the models) Incorrectly ti ghtened terminals may cause the terminal unit to heat up and invalidate the • warranty. • Before any work inside the device, you must cut the electricity supply as there is a risk of electric shock which may cause material damage, serious injury or even death. -
Page 9: ❸ Use
❸ Use • Never run the circulati ng pump (depending on the model) without water. The circulati ng pump is very quiet when it starts up; you may not hear it running. 3.1 I Operati ng principle Your heat pump uses the calories (heat) from your home's heati ng to heat up your pool's water. The heat is exchanged through a series of pipes;... -
Page 10: I Operati Ng
3.3 I Operati ng • Never run the circulati ng pump (depending on the model) without water. The circulati ng pump is very quiet when it starts up; you may not hear it running. • Never run any water through the primary circuit without any water running through the secondary circuit. -
Page 11: I Additi Onal Functi Ons
3.4 I Additi onal functi ons 3.4.1 Setti ng the setpoint on Heat Line + and SC To display and modify the set point value, press 3.4.2 Locking / unlocking the circulati on pump keypad on Heat Line + Press and hold for 10 seconds. -
Page 12: ❹ Maintenance
❹ Maintenance 4.1 I Wintering • Wintering is vital to prevent the condenser breaking due to freezing. This is not covered by the warranty. • To avoid damaging the electrical box with condensati on, do not fully cover it. • Only the plug's seal ensures water ti ghtness. Replace it without using hemp! To ensure a waterti ght seal and avoid damaging the threads, do not overti ghten the plug + seal assembly. -
Page 13: ❺ Troubleshooti Ng
❺ Troubleshooti ng • Before you contact your reseller, please carry out these few simple checks using the following tables if a problem occurs. • If the problem conti nues contact your reseller. If the problem conti nues contact your reseller. •... -
Page 14: I Error Code Display
5.2 I Error code display Regulator display Possible causes Soluti ons The regulati on sensor is out of Reconnect or change the sensor service or disconnected Flashing Circulati ng pump display Possible causes Soluti ons (fi rst LED red) • The circulati ng pump has •... -
Page 15: I Wiring Diagram
5.4 I Wiring diagram 19-20 Dry command contact "normally open" Pool water regulati on sensor (PTC) power cable: 2L+E 10/16A 3G1 Regulati on thermostat with digital display Flow controller White 3.15 A-T protecti on fuse blue Black duct brown "On/off " LED black "Reg"... - Page 16 Votre revendeur Your retailer Modèle appareil Appliance model Numéro de série Serial number Trouvez plus d’informations et enregistrez votre produit sur More informations and register you product on www.zodiac-poolcare.com ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
