- Page 1 Heat Line Instructions for installation and use - English Heat exchanger Translation of the original instructions in french More documents on: www.zodiac.com H0360800.E - 2021/01...
- Page 2 WARNINGS Carefully read the instructions in this manual before using the unit. • Before handling the appliance, it is vital that you read this installation and user manual, as well as the "Warranties" booklet delivered with the appliance. Failure to do so may result in material damage or serious or fatal injury and will void the warranty.
- Page 3 WARNINGS ASSOCIATED WITH ELECTRICAL APPLIANCES • The power supply to the appliance must be protected by a dedicated 30 mA Residual Current Device (RCD), complying with the standards and regulations in force in the country in which it is installed. •...
-
Page 4: Table Of Contents
CONTENTS ❶ Specifications 1.1 I Description 1.2 I Technical specifications 1.3 I Dimensions and marking ❷ Installation 2.1 I Selecting the location 2.2 I Hydraulic connections 2.3 I Electricity supply connections (depending on the model) ❸ Use 3.1 I Operating principle 3.2 I User interface presentation (depending on the model) 3.3 I Operation 3.4 I Additional functions... -
Page 5: ❶ Specifications
❶ Specifications 1.1 I Description Heat Line Plus Heat Line Plus without circulating pump Bare Heat Line 1.2 I Technical specifications Heat Line Power with primary circuit at 90°C (kW) Power with primary circuit at 60°C (kW) Power with primary circuit at 45°C (kW) Primary circuit flow rate (m³/h) Secondary circuit flow rate (m³/h) Primary circuit head loss (bar) -
Page 6: I Dimensions And Marking
1.3 I Dimensions and marking Front Heat Line 20-40 535 mm 665 mm 198 mm 328 mm Plus with Plus without Heat Line Bare circulating pump circulating pump Multi-tube exchanger body ½ union PVC connector Ø63 to be glued Primary circuit drainage cap Glove finger Regulation sensor Circulating pump... -
Page 7: ❷ Installation
❷ Installation 2.1 I Selecting the location • The appliance must be installed in a technical room ventilated, dry and without stored pool treatment products. • The appliance must be installed before any water treatment system. • Install the appliance as close as possible to the heating source (boiler, heat pump, geothermal, solar-powered heating, etc.), •... -
Page 8: I Hydraulic Connections
2.2 I Hydraulic connections • Respect the hydraulic connection direction (see the indications on the exchanger tank). • Correctly tighten the hydraulic connections and check for leaks. • Check that the pipe system is cleaned before connecting anything. : Pool water inlet valve : Pool bypass valve : Pool water outlet valve : Heating water inlet valve... -
Page 9: I Electricity Supply Connections (Depending On The Model)
2.3 I Electricity supply connections (depending on the model) Incorrectly tightened terminals may cause the terminal unit to heat up and invalidate the • warranty. • The appliance must be connected to an earth socket. • Before any work inside the appliance, you must cut the electricity supply as there is a risk of electric shock which may cause material damage, serious injury or even death. -
Page 10: ❸ Use
❸ Use • Never run the circulating pump (depending on the model) without water. The circulating pump is very quiet when it starts up; you may not hear it running. 3.1 I Operating principle The heat pump uses the calories (heat) from the home's heating to heat up the pool's water. The heat is exchanged through a series of pipes: the home's heating water circulates through the exchanger's body and the pool water circulates through the pipes. -
Page 11: I Operation
3.3 I Operation • Never run the circulating pump (depending on the model) without water. The circulating pump is very quiet when it starts up; you may not hear it running. • Never run water through the primary circuit when there is no water running through the secondary circuit. -
Page 12: I Additional Functions
3.4 I Additional functions 3.4.1 Setting the setpoint on Heat Line Plus with and without circulating pump To display and modify the set point value, press 3.4.2 Operation of the circulating pump on Heat Line Plus Tip: Choosing the right operating mode •... -
Page 13: ❹ Maintenance
❹ Maintenance 4.1 I Winterising • Winterising is vital to prevent breakage due to freezing. This is not covered by the warranty. • To avoid damaging the switch box with condensation, do not fully cover it. • Only the plug's gasket ensures water tightness. Replace it without using hemp. •... -
Page 14: ❺ Troubleshooting
❺ Troubleshooting • Before you contact the retailer, carry out these few simple checks using the following tables if a problem occurs. • If the problem is not resolved, contact your retailer. • : Actions to be performed by a qualified technician only 5.1 I Appliance behaviour •... -
Page 15: I Error Code Display
5.2 I Error code display Regulator display Possible causes Solutions The regulation sensor is out of Reconnect or change the sensor service or disconnected Flashing Circulating pump Possible causes Solutions display (first LED red) • The circulating pump has detected an electrical •... -
Page 16: I Wiring Diagram
5.4 I Wiring diagram 19-20 Dry command contact "Normally Open" Pool water regulation sensor (PTC) Power cable: 2L+E 10/16A 3G1 Regulation thermostat with digital display Flow switch White 3.15 A-T protection fuse Blue Black duct Brown "On/off" LED Black "REG" LED flashing when timed or fixed heating Green - Yellow in progress Circulating pump motor... - Page 17 Pour plus d’informations, enregistrement produit et support client : For more information, product registration and customer support: www.zodiac.com ©2020 Zodiac Pool Systems LLC. All rights reserved. ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license. All other trademarks are the property of their respective owners.
